Product Description
Security samrt electronic lock for cargo monitiring container vehicle location

JT705A currently supports 2G/4G communication mode, with keyless design, RFID/remote unlocking;Built-in wireless module, real-time online monitoring;Built-in GPS module, global positioning tracking;Security monitoring, illegal unlocking alarm upload and other functions.

It is suitable for logistics tracking management of container trucks and container boxes, and remote asset management and control.The length of the lock bar is adjustable to adapt to the lock bar distances of different pitches.
Functions
Main functions
Function description
Positioning
GPS + LBS
Dual SIM card
Support two Micro-SIM cards, dual card single standby mode work.
Adjustable lock bar length
To adapt to the lock bar distance of different pitches
Voice prompts and OLED screen
Different voice prompts in different operating scenarios
DC 12V/ 3A charging
The battery can be fully charged in about 10 hours
Internal battery 26500mAh
Rechargeable lithium battery,can last 180 days
Spare battery
Turn on the spare battery when the main battery is out of power
Serial port
Can be used for firmware upgrade, parameter configuration, DEBUG debugging
Six-axis acceleration sensor
Motion and vibration detection
contact me for more details
Product Paramenters
Item
Description
Dimension（L*W*H）
255*135*53mm
Length of latch
486mm
Weight
4.2kg（With standard accessories）
Shell material
Aluminum alloy + polycarbonate
Built-in battery
26500mAh rechargeable lithium battery
Operating temperature
-20℃ ~ 70℃
Storage temperature
-40℃ ~ 80℃
Relative humidity
5%~95%
Waterproof and dust-proof grade
IP67
Charging voltage/current
DC12V/3A
Average sleep current
4G
Enable SMS wake-up:14.4mA
Turn off SMS wake-up:2.17mA
2G
Enable SMS wake-up:6.9mA
Turn off SMS wake-up:1.91mA

Average working current
2G: 30.3mA
4G: 48.7mA
GNSS/ Cellular module antenna
Built-in
GNSS module
Ublox-MAX-8Q
Product Application
