Round Bar Cutting Machine
Steel bar cutting machine is applicable to normal carbon steel, hot rolled round steel and screw steel in all kinds of reinforced
concrete in construction engineering.Flat, square and Angle steel can be cut off
Model |
GQ40A |
GQ40B |
GQ45 |
GQ50A |
GQ50B |
||||
Cutting range (mm) |
Round bar:6-30 class bar 6-25 |
Round bar:6-32 class bar6-28 |
Round bar:6-35 class bar:6-30 |
Round bar:6-42 class bar:6-38 |
Round bar:6-40 class bar:6-36 |
||||
Cutting frequency |
32times/min |
32times/min |
30times/min |
28times/min |
28times/min |
||||
Motor power |
2.2kw |
3kw |
3kw |
4kw |
4kw |
||||
Input voltage |
Three phase 220v/380v/415v or customized |
||||||||
Motor speed |
2800rpm |
||||||||
Blade size(mm) |
83*83*16 |
83*83*26 |
83*83*26 |
90*90*26 |
90*90*26 |
||||
Overall size(mm) |
1330*460*750 |
1330*460*750 |
1330*460*790 |
1500*500*620 |
1330*500*620 |
||||
Weight(kg) |
240 |
260 |
400 |
450 |
484 |
||||
Gear
-The whole gear steel die-casting, six times quenching forging, more durable, gear shaving process to reduce the working noise
Principal axis
-The use of bevel tooth spindle, bevel teeth greatly increased the power of the machine, spindle shaving process, effectively reduce the working noise
Travel switch
-Genuine delixi travel switch, precise bending Angle, long life of the switch is not easy to damage, improve work efficiency
Gear Box
-The heavy and thick cast steel plate is made by sand removal process, which has longer service life
Delivery within 5 working days.
Package in wooden case.
Minimum order quantity : 1 SET
Factory Sale, Support Custom
MOQ of Custom: 6 SET
Please feel free to contact us for any questions!
We welcome every customer and solve your problem seriously.
Please contact us below, Send us a inquiry with your quetions↓↓↓↓↓
