Diesel Engine Mobile Hydraulic Water Well Drilling Machine With Mud Pump and Drilling Bits in China photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1998
Annual Export Value:
Below US$1 Million
Contact Supplier Request Quote Chat Now
Shandong Hengwang Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
****HW-Hydraulic DRILLING RIG
HWseries hydraulic drilling rig is a kid of widely used portable drill machine. It is uitbale for drilling water well, geological survey, geological core drilling, small grouting holes, blasting holes of railway, water conservanc, bridges, dam foundation and other buildings. According to different strata, it drills by choosing different bits, such as, diamond composite films and alloy.
****Main features
1.It improves drilling efficiency and reduces labor intensity with hydraulic automatic feeding mechanism.
2.It can be achieved without stopping to change rods, easy to operate, safe and reliable with ball clip holding mechanism or hydraulic chuck.
3.It has hole bottom pressure gauge to be easy tp master the situation in the hole.
4.It also has advantage of compact structure, concentrated handle, small footprint, light weight, strong decomposition, easy to move.It can be operated in plains and mountain areas.
Mobile hydraulic well drilling rig technical specifications：



Weight
600/650/850KG
Spindle Speed
64~1045(r/min)
Max.Drilling depth
160m/190m/230m
Spindle Stroke
450mm
Soil Open hole dia.
500mm/500mm/500mm
Winch single rope lift force
2000kg-2500kg
Rock Open hole dia.
220mm/220mm/273mm
Winch single rope lift speed
0.12-1.64(m/s)
End hole dia.
75mm~200mm
Winch Rope dia.
9.3mm/9.3mm/12..5mm
Drill rod dia.
42/50/60
Winch Rope capacity
27M/27M/35M
Drill angle
90-75°
Drill Mast Rated load
18T
Engine Power
13/14/16KW
Drill Mast Effective height
6.5M
Inlet hose dia.(mm)
51mm
Mud pump Flow
95~145L/min
Dimension
2.7*0.9*1.5
Mud pump ure
1.2~2Mpa
Outlet hose dia.(mm)
32mm
Mud pump reciprocations time
93 times/min
Detailed Images
High Quality portable water well drilling rig rock bore drilling machine
Work shop
230-300m Deep Portable Water Well Drilling rig with hydraulic drilling rig and mud pump
