New 250hp 19500kg large motor grader 425 with 6LTAA8.9-C240 EURO II engine

Product Description

Fuel Efficient Dongfeng Cu-mmins Engine.
Low Vibration, Noise, Dust +UV Resistant cab
Z-F wet axle with "no-spin" differential lock as standard
Balance box enables the 4 rear wheels to swing up and down by +/- 15°
AWD and 4WD



Operating weight 19500 kg
Weight on front wheels 5850 kg
Weight on rear tandem 13650 kg
Drawbar pull 100 kN
Model Cu-mmins 6LTAA8.9-C240
Emission regulation Tier 2 / Stage II
Rated power 179 kW (243 hp) @ 2200 rpm
Net power 162 kW (220 hp) @ 2200 rpm
Type Power shift
Speeds 6f / 3r
Maximum travel speed, forward 36.6 km/h
Maximum travel speed, reverse 23 km/h
Turning radius 8000 mm
Articulation angle ±20°
Maximum overall height 3460 mm
Width over tires 2915 mm
Blade width 4572 mm
Overall length 9570 mm
