165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165

165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165 photo-1
165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165 photo-2
165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165 photo-3
165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165 photo-4
165HP Chinese Brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165 photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

High Performance New Motor Grader 140K With Ripper And Blade

Product Description

 LIUGONG motor grader adopts the external ring gear type working device to achieve higher transmitted torque, larger blade cutting angle, and better material control capability and features the maximum traction force among the domestic like machines. This machine is applicable for large-area leveling, ditching, slope scraping, bulldozing, ripping, land clearing, and snow removing and is an ideally essential machine for large building constructions, water conservancy projects, and farm.

Parameter



Operating weight

13500 kg

Weight on front wheels

4050 kg

Weight on rear tandem

9450 kg

Drawbar pull

70 kN

Model

6BTAA5.9-C150

Emission regulation

Tier 2 / Stage II

Rated power

112 kW (152 hp) @ 2200 rpm

Net power

100 kW (136 hp) @ 2200 rpm

Type

Power shift

Speeds

6f / 3r

Maximum travel speed, forward

41 km/h

Maximum travel speed, reverse

29 km/h

Turning radius

7200 mm

Articulation angle

±20°

Maximum overall height

3350 mm

Width over tires

2470 mm

Blade width

3660 mm

Overall length

8400 mm

Photo for reference

 165HP Chinese brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165165HP Chinese brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165165HP Chinese brand High Performance New Motor Grader 140K With Ripper And Blade CLG4165
