Earth Moving Machinery GR180 Small 180 hp Road Motor Grader Machine Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
180HP New Hydraulic Small Motor Grader for Road Construction GR1803NegotiableMOQ: 1 -
High Quality GR2405 230hp Motor Grader For Sale With Best PriceNegotiableMOQ: 1
-
Official 6m Road Paver RP603 China Asphalt Concrete Paving Crawler Road Machine PriceNegotiableMOQ: 1
-
Official Manufacturer 7.5m Asphalt Concrete Paver RP756 With High DumpingNegotiableMOQ: 1
-
RP753 Pavement Finishing 8m Concrete Paver in New Good ConditionNegotiableMOQ: 1
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Products Description
Motor Grader Models We Can Supply:
100HP GR100, GR1003
135HP GR135, GR1353
165HP GR165, GR1653
180HP GR180 , GR1803
215HP GR215, GR2153
240HP, GR240, GR2403
300HP, GR300, GR3003
Specification
Product advantages:
♠ New Appearance Design.
♠ Articulated frame with front wheel steering, small turning radius and flexible maneuverability.
♠ Electro-hydraulic control power shift gearbox, 6 gears forward and 3 gears backward.
♠ Internationalized hydraulic fittings, reliable operation.
♠ The action of spade is controlled by full hydraulic pressure.
♠ The rear axle is a three-stage drive axle equipped with NO-SPIN self-locking differential.
♠ The control platform and seat can be adjusted, the control handle and instrument are arranged reasonably, the use is convenient, and the driving comfort is improved.
♠ The cab is luxurious and beautiful, with wide vision and good sealing.
♠ It can be equipped with front bulldozer, back looser, front looser rake and automatic leveling device.
♠ New Appearance Design.
♠ Articulated frame with front wheel steering, small turning radius and flexible maneuverability.
♠ Electro-hydraulic control power shift gearbox, 6 gears forward and 3 gears backward.
♠ Internationalized hydraulic fittings, reliable operation.
♠ The action of spade is controlled by full hydraulic pressure.
♠ The rear axle is a three-stage drive axle equipped with NO-SPIN self-locking differential.
♠ The control platform and seat can be adjusted, the control handle and instrument are arranged reasonably, the use is convenient, and the driving comfort is improved.
♠ The cab is luxurious and beautiful, with wide vision and good sealing.
♠ It can be equipped with front bulldozer, back looser, front looser rake and automatic leveling device.
Item |
Parameters |
Unit |
Engine Model |
6CTA8.3-C215 |
GR180 |
Rated power/speed |
160/2200 |
kW/rpm |
Exterior dimensions of the whole machine (standard) |
8970×2625×3420 |
mm |
Weight of the whole machine (standard) |
16500 |
kg |
Speed of advance |
5,8,11,19,23,38 |
km/h |
reverse speed |
5,11,23 |
km/h |
Traction f = 0.75 |
90 |
kN |
Max Climb Capability |
20 |
% |
Maximum lifting height |
450 |
mm |
Minimum turning radius |
7.3 |
m |
Maximum shovel depth |
500 |
mm |
Maximum roll angle |
90 |
° |
Return angle |
360 |
° |
