Brand New 220hp Motor Grader SEM921 Motor Graders 140g
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
135hp Small Motor Grader GR135 Mini Road Grader for SaleNegotiableMOQ: 1 -
Popular 215HP New Motor Grader CLG4215D for SaleNegotiableMOQ: 1
-
30 Ton Pneumatic Tyres Road Roller XP303KNegotiableMOQ: 1
-
16t/18t/20t Pneumatic Tyre Road Roller LTP2030/LTP1826/LTP1016NegotiableMOQ: 1
-
Full Hydraulic 14t Double-wheel Drive Single Drum Road Roller XS143NegotiableMOQ: 1
Brand new 220hp motor grader SEM921 motor graders 140g
Tandem Axle
* Leveraging designing and experience on MG tandem axle
* Improved bearing Layout and optimized load distribution with 4 planetary gears final drive
* Less down time and reduced labor and service cost for maintenance and repairing
* Longer service interval for lubrication oil change
* Leading in class manufacturing and quality control level, mandatory performance testing before delivering to MG assembly line
Control System
* 7 position link bar with electric over hydraulic control allows ease of operation from within the cab
* Optimum blade reach capability, quick DCM re-positioning for greater reach for better working on high bank side slope
* The link bar is essential for extending reach capability when cutting a bank slope or back slope of a ditch
* Replaceable bushings reduce service time and cost
* Leveraging designing and experience on MG tandem axle
* Improved bearing Layout and optimized load distribution with 4 planetary gears final drive
* Less down time and reduced labor and service cost for maintenance and repairing
* Longer service interval for lubrication oil change
* Leading in class manufacturing and quality control level, mandatory performance testing before delivering to MG assembly line
Control System
* 7 position link bar with electric over hydraulic control allows ease of operation from within the cab
* Optimum blade reach capability, quick DCM re-positioning for greater reach for better working on high bank side slope
* The link bar is essential for extending reach capability when cutting a bank slope or back slope of a ditch
* Replaceable bushings reduce service time and cost
Specification
Model |
SEM919 |
Standard |
15,070 kg / 15.370 kg (With ROPS) |
With Front & Rear Counterweight |
15,870 kg / 16,170 kg (With ROPS) |
With Front Blade |
16,270 kg / 16,570 kg (With ROPS) |
With Ripper+Front Blade |
17,280 kg / 17,580 kg (With ROPS) |
Top Speed, Forward |
40 kph |
Top Speed, Reverse |
25 kph |
Min. Turning Radius |
7,800 mm |
Articulation Angle, Left /Right |
20 ° |
Gradeability |
30 ° |
Wheelbase |
6,140 mm |
Travel Speed, Forward |
5.3/9.1/12/20/25/40 kph |
Travel Speed, Reverse |
5.3/12/25 kph |
Drawbar Pull |
85 kN |
Model |
SEM921 |
Operating Weight |
15,930 kg |
Engine Model |
SC9D220G2 |
Rated Power |
162 kW/217 hp |
Overall Dimensions L*W*H |
8854x2630x3360 mm |
Blade Length |
4,279 mm |
Max. Drawbar |
85 kN |
Max. Lift above Ground (Blade) |
475 mm |
Max. Depth of Cut (Blade) |
715 mm |
Max. Blade Tip - Forward |
40º |
Max. Blade Tip - Rear |
5º |
Front Axle Steering Angle Left/Right |
47.5º |
Min. Turning Radius |
7.8 m |
Tandem Oscillation (Front up) |
15º |
Tandem Oscillation (Rear up) |
25º |
Transmission Model |
6WG180 |
Gears |
F6/R3 |
Tires |
17.5-25 |
Details Images
