Products Description
New 55 Ton Crawler Crane XGC55 Factory Stock Price
XGC55 is designed and developed independently in absorption of foreign advanced technology and combined with China domestic work conditions.
1. Optimized hydraulic system design
* Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance.
* Use of highly integrated LUDV main valve, with the functions of multi-com- plex operation, control of combined flow, high/low speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
2. Main/ auxiliary hook one-key-switch-over function
One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
1. Optimized hydraulic system design
* Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance.
* Use of highly integrated LUDV main valve, with the functions of multi-com- plex operation, control of combined flow, high/low speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
2. Main/ auxiliary hook one-key-switch-over function
One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
Specification
Items | Unit | Parameter value |
Max. rated lifting load of main boom | (t) | 55 |
Max. rated lifting load of fixed jib | (t) | 11.4 |
Max. lifting load moment | (t.m) | 203.5 |
Max. rated lifting load of boom single pulley | (t) | 6 |
Main boom length | (m) | 13~52 |
Main boom luffing angle | (°) | -3~80 |
Fixed jib length | (m) | 7~16 |
Max. size of single unit for transport (L×W×H) | (m) | 12.04×3.45×3.36 |
Installation angle of fixed jib | (°) | 10,30 |
Max. single line speed of hoist system | (m/min) | 125 |
Max. single line speed of main luffing system | (m/min) | 87/78 |
Max. slewing speed | (r/min) | 2.45/2.2 |
Max. travel speed | (km/h) | 1.37/1.22 |
Gradeability | (%) | 30 |
Average ground pressure | (MPa) | 0.06 |
Model | - | SC7H210.1G3/QSB6.7 |
Engine power | (kW) | 155/153 |
Emission | - | National III stage/Europe III |
Crane overall mass | (t) | 46.3(Main hook,13m boom) |
Max. weight of single unit for transport | (t) | 28.6 |
