Lonking biggest hydraulic crawler excavator CDM6485H with 48 tons operating weight

Name: Lonking biggest hydraulic crawler excavator CDM6485H with 48 tons operating weight
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Product Description

Lonking biggest hydraulic crawler excavator CDM6485H with 48 tons operating weight

Product Description

Cu-mmins TDCI 4-cylinder engine

Three-stage air and fuel filtering system

Air-air inter cooling system with parallel radiator

Dual-pump double-circuit constant power control hydraulic system

Multi-purpose true color monitor with large screen

No frame cab glasses to enlarge the visual field

High performance and healthy A/C allows the air circulate

Comfortable suspension seat with hydraulic damper

Safe and comfortable cabin with 2.7m³ inner space

Free maintenance track with non- lubricated pins

Heavy-duty boom and arm with high strength low alloy structural steels

Heavy-duty bucket with high strength and wear-resistant steels

Model		CDM6485H
General	Operating weight( kg)	48200
	Standard bucket(m³)	2.2
	Bucket range(m³)	2.2-2.5
	Ground pressure(kPa)	83
	Travel speed(km/h)	3.3/5.32
	Swing speed (rpm)	9.5
	Gradeability	35° (70%)
Engine	Model	Cu-mmins QSM11 (Euro IIIA)
	Rated power(Kw(hp)/rpm)	269(360)/1850
	Displacement (L)	11.04
	Fuel tank(L)	655
Hydraulic System	ure of Implements(MPa)	35.3
	Max. flow of system( L/min)	370x2
	Hydraulic oil tank(L)	480
Working Device	Boom length(mm)	7060
	Arm length(mm)	3380
	Bucket radius(mm)	1800
Digging Force	Max. arm digging force (SAE/ISO)(kN)	214/218
