SEM 655D 5 TON Wheel Loader
Product Description
Specification
655D
Rated capacity
3m³
Rated weight
5000Kg
Operating weight
16000Kg
Performance of bucket being set level
Yes
Static tilting load at full steering position
98KN
Max. breakout force
172.6KN
Max. drawbar pull
151.9KN
Max. grade ability
30°
Total of three time:lifting,dumping, lowering
11.3s
Max.dump height
3098mm
Max.dump reach
1198mm
Min. ground clearance
450mm
Wheel base
3200mm
Overall dimensions(length*width*height)
7836*3010*3300mm
Engine
STEYR
Model
WD10G220E22
Pattern
Inline, water cooled, direct. inject, four strokes
Cylinder-bore*stroke
6-126*130
Max.torsion
779Nm
Rated power
162KW
Min.fuel consuming rate
214g/kw.h
Specified rotational speed
2200r/min
Model of torque device
YJ375
Pattern
3-element,single stage
Number of great shift
4 forward,4 revers
Max. travel speed
38km/h
Main reducer type
Spiral bevel gear, moderation of first stage
Pattern of wheel side moderation
Single stage planetary
Type size
23.5-25
Front type pressure
392KPa
Rear type pressure
343KPa
Pattern
Articulated and hydraulic steering, load sensing meets
Steering angle(each direction)
35°C±1
Min. turning radius(outside of bucket)
7268mm
Valve distributing working
DF32·2C
Working pumps
CBG3100
Brake system
Air assisted oil type four wheel brake
Parking brake
Air cutting control inner expand hoof
Fuel capacity
320L
Pressure of working hydraulic system
160kfg/cm2
Specifications

Heavy Duty 5 Ton SEM655D sugar cane grab loader for sale
*Rated loading weight: 5,000kg
*Rated capacity: 3.0cbm
*Operating weight: 17,000kg
*Engine: WD10G220E22
Details Images
Reliable Drivetrain
1)Countershaft transmission with upgraded core components provides high reliability
2)Large rim-pull in 1st gear and higher speed in 2nd gear provide high efficiency for load and carry applications
3)Clutch cutoff selection switch ensures stable and safe operation
4)Torque convertor structure is simple and efficiency is high
5)The SEM designed and built axle provides best in class performance in heavy duty applications

Serviceability

1)System pressure test ports are standard
2)Big angle engine hood side open door provides easy service access
3)Torque convertor is isolated from transmission making it easy to service

Weichai Engine

1)SEM655D’s low speed engine with E-fan provides increased operating efficiency
2)SEM655D owned enhanced fuel pre-filter eliminates water and contaminant from fuel for best fuel system protection
3)SEM655D’s air cleaner provides machine reliability even in the most severe applications

Safety

1)Safety design complies with all regulatory requirements
2)SEM Production System (CPS) leveraged in manufacturing process
3)3-point touching design provides convenient operator entering to cabin
4)Backup alarm ensures machine safety
5)Environmentally friendly painting process

Operator Station

1)Premium operator station with big space and superior visibility
2)Adjustable suspension seat
3)Sliding side window and AC with fresh air circulation provide operator comfort
4)Single lever shifting is flexible and convenient
5)Adjustable air flow outlet delivers better defrost performance
6)Patented MAC mount provides less noise and increased comfort
