Small Self Loading Cargo Truck Dump Trucks China Mini Dumper For Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cargo Dumper Self Loading Dumper Mini Utility Truck For Construction WorksNegotiableMOQ: 1 -
Fcy50S Brand New Dump Trucks Sale Mini Dump Trucks For SaleNegotiableMOQ: 1
-
Small Site Truck 5ton Hydraulic Dumper 5tons Dumper TruckNegotiableMOQ: 1
-
Fcy50S 5ton Off Load Site Dumper Truck Rubber Track Dumper Truck With Low PriceNegotiableMOQ: 1
-
2022 FCY50S 5 Ton New Mini Loader Dumper for SaleNegotiableMOQ: 1
FCY50S 5ton Self Loading Dumper
Products Description
MAIN TECHNICAL SPECIFICATIONS |
||
MODEL |
FCY50S |
|
BUCKET CAPCITY |
2.0M3 |
|
RATED LOAD |
5000KG |
|
OPREATING WEIGHT |
2850KG |
|
MAX TRACTION |
45KN |
|
GRADBILITY |
30° |
|
MINI TURNING RADICUS |
4000MM |
|
GROUND CLEARANCE |
248MM |
|
NOISE LEVEL |
≤102db(A) |
|
LOADING DISCHARGE ANGLE |
48.40° |
|
TIME OF DISCHARGE |
8S |
|
TREAD |
1580MM |
|
WHEEL BASE |
2000MM |
|
OVERALL DIMENSION |
L4250*W1950*H2300 |
|
ENGINE |
||
MODEL |
WEICHAI HUAFENG4102 |
|
TYPE |
UP-RIGHT,WATERCOOLED,4 STOKES,4CYLINDERIN-LINE,DIRECT FUEL INJECTION |
|
FUEL CONSUMPTION |
248g.kw/h |
|
SPEED |
2400R/MIN |
|
BORE*STROKE PISTON |
100*102 |
|
WEIGHT |
350KG |
|
RATED POWER |
47KW |
|
MAX TORQUE |
270N.M |
|
DRIVE SYSTEM |
||
GeraBOX |
GEAR TRANSMISSION BOX |
|
CLUTCH |
DRY FRICTION CLUTCH,SINGLE DISC, |
|
DRIVE SHAFT |
TUBULAR-TYPE,OPEN-TYPE,RIGIDLE-BEARING UNIVERSAL JIONT |
|
NOS OF SHIFTS |
FOUR FRONT/BACKWARD SPEEDS |
|
MAX SPEED |
25KM/H |
|
REAR AND FRONT ALEX |
FOUR-WHEEL DRIVE,Front axle fixed,Rear axle moved(+/-11°) |
|
STEERING TYPE |
FULL-HYDRUALIC STEERING SYSTEM,CONTROL BY WHEEL,TWO CYLINDERS DOUBLE ACTING |
|
STEERING ANGLES |
35° |
|
HYDRAULIC SYSTEM |
||
WORKING PRESS |
160(kgf/c m2),16MPA |
|
HYDRAULIC PUMP |
GEAR PUMP |
|
DISTANCE AFTER BRAKE |
≤2.5M with load and speed 10km/h |
|
OPREATING BRAKE |
Hydraulic shoe system,four wheel mounted |
|
Handbrake |
mechanically-pirated central sport-type disc |
|
BRAKE TYPE |
OIL BREAKE |
|
TYRE SIZE |
20.5/70-16 |
|
FRAME |
Channel steel welding type,two-section articulated connection |
|
wheel rim |
9.75H |
|
FUEL TANK |
50L |
|
HYDRAULIC TANK |
30L |
|
BATTERY |
24V lead storage battery |
|
Details Images
Company Profile
FAQ
1.How can I place order?1.How can I place order?
A: You can contact us by email about your order details, or place order on line.
2.How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T or start order from Alibaba trade assurance
3. Are you factory supplier?
A: Yes, we are real factory supplier for over10years, own a super technical team to serve adjusting design for customers
4.How many tons site dumper do you produce ?
A:We are specilized in producing site dumper cover 1ton to 10tons. Model:FCY10, FCY20, FCY30, FCY50, FCY70, FCY100.
5. Which brand engine do you have for site dumpers?
A:We company choose good quality engine for site dumpers, Changchai, Xichai, Weichai Power engine / cummins engine/ Deutz diesel engine and so on optional.
6. What's the order procedure?
A: First we discuss order details, production details by email or TM.Then we issue you a PI for your confirmation.You will be requested to do prepaid full payment or deposit before we go into production.After we get the deposit, we start to process the order.We usually need 7-15 days if we don't have the items in stock.Before production has been finished,we will contact you for shipment details, and the balance payment.After payment has been settled, we start to prepare the shipment for you.
