CHINA SNS PNEUMATIC



Model | 2W350-35 |
Fluid | Air/Water/Oil |
Action Mode | Pilot-operated type |
Type | Normal Closed |
Port Diameter(mm2) | 35 |
CV Value | 24 |
Port Size | G1 ¼ |
Fluid Viscosity | Under 20 CST |
Working Pressure | Water/Oil: 0.1-0.5MPa Air: 0.1-0.7MPa |
Proof Pressure | 1.0MPa |
Temperature | -5-85℃ |
Working Voltage Range | ±10% |
Material Body | Brass |
Material Seal | NBR |
Coil Power | 50VA |
Installation | Horizontal Installation |

Model | A | B | C | D | K |
2W350-35 | 134.5 | 92.5 | 159 | 120 | G1 ¼ |
