SNS 2W160-15 Normally Closed Electric Control 1/2 Inch Water Solenoid Valve
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1990
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return ValveNegotiableMOQ: 1 -
SNS 2W400-40 24v dc Brass Solenoid Valve WaterNegotiableMOQ: 1
-
SNS 2W500-50 High Quality Pilot-operated 2 Inch Water Solenoid ValveNegotiableMOQ: 1
-
SNS 2W200-20 Wholesale Control Valve Brass Water Solenoid ValveNegotiableMOQ: 1
-
SNS Q22HD Series Two Position Two Way Copper Pneumatic Air Control Cut-off ValveNegotiableMOQ: 1
Banner
CHINA SNS PNEUMATIC
------ Leading supplier of pneumatic components in China -----
Products Description
Model |
2W160-15 |
Fluid |
Air/Water/Oil |
Action Mode |
Pilot-operated Type |
Type |
Normal Closed |
Port Diameter(mm2) |
16 |
CV Value |
4.8 |
Port Size |
G1/2 |
Fluid Viscosity |
Under 20CS |
Working Pressure |
Water/Oil: 0-0.5MPa Air: 0-0.7MPa |
Proof Pressure |
1.0MPa |
Temperature |
-5-85℃ |
Working Voltage Range |
±10% |
Material Body |
Brass |
Material Seal |
NBR |
Coil Power |
20VA |
Model |
A |
B |
C |
D |
K |
2W160-15 |
93 |
55.5 |
106.5 |
67.5 |
G1/2 |
Certifications
FAQ
Q1. Are you a manufacturer or a trading company?
A1. We are a leading manufacturer of all pneumatic products. Welcome to visit our factory at any time.
Q2. What’s the payment term?
A2. T/T, MasterCard, VISA, E-Checking, Boleto, Pay Later.
Q3. How about the delivery time ?
A3. 1-3 days for normal models. For big orders, it takes about 10-15 days.
Q4. What is the standard of package?
A4. Export standard package or special package according to customers' requirement.
Q5. What kind of product quality does your factory offer?
A5. We are top 3 supplier in Chinese market. We offer top quality to our clients.
Q6. Do you accept OEM business?
A6. We do OEM .
Q7. What market do you already sell to?
A7. We already ship to Asia, Europe, North America, South America, Africa, Oceania.
Q8. What kind of certificate do you have ?
A8. We have ISO9001, CE, CCC, etc.
