Home > Industrial Equipment & Components > Valve > Ball Valve > SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve thumbnail-1
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve thumbnail-2
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve thumbnail-3
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve thumbnail-4
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve thumbnail-5
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve photo-1
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve photo-2
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve photo-3
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve photo-4
SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1990
Annual Export Value:
US$2.5 Million - US$5 Million
Contact Supplier Request Quote Chat Now
China SNS Pneumatic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

Banner

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

Product Description

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return ValveSNS CV Series One Way Nickel-Plated Brass Check Valve Non Return ValveSNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve



Model CV-01 CV-02 CV-03 CV-04
Working Media Compressed Air
Port Size G1/8 G1/4 G3/8 G1/2
Max.Working Pressure 1.0Mpa
Proof Pressure 1.5Mpa
Working Temperature Range 0-70℃
Material Body Brass
Seal NBR

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

Model A B ØC
CV-01 42 14 G1/8
CV-02 50 17 G1/4
CV-03 50 21 G3/8
CV-04 63 27 G1/2

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return ValveSNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

CHINA SNS PNEUMATIC

------Leading supplier of pneumatic components in China-----

Certificate

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve

Packaging & Shipping

SNS CV Series One Way Nickel-Plated Brass Check Valve Non Return Valve



FAQ

Q1. Are you a manufacturer or a trading company?A1. We are a leading manufacturer of all pneumatic products. Welcome to visit our factory at any time.

Q2. What’s the payment term?A2. T/T,  MasterCard,  VISA,  E-Checking,  Boleto,  Pay Later.

Q3. How about the delivery time ?A3. 1-3 days for normal models. For big orders, it takes about 10-15 days.

Q4. What is the standard of package?A4. Export standard package or special package according to customers' requirement.

Q5. What kind of product quality does your factory offer?A5. We are top 3 supplier in Chinese market. We offer top quality to our clients.

Q6. Do you accept OEM business?A6. We do OEM .

Q7. What market do you already sell to?A7. We already ship to Asia,  Europe,  North America,  South America,  Africa,  Oceania.

Q8. What kind of certificate do you have ?A8. We have ISO9001,  CE,  CCC,  etc.
