Capillary Tube Mats
Product Parameters
Product |
Capillary Tube Mat (Distributor tubes with open welding ends) |
Material |
Polypropylene (PP-R) & Blue |
Collector pipe size |
20*2.0 mm |
Capillary tube size |
4.3*0.8 mm |
Spacing of Capillary tubes |
10mm, 20mm, 40mm, Z20mm, Z40mm |
Length |
600mm - 12,000 mm |
Width |
1000mm |
Connection method |
Connect mats to another and to the water circuit by means of thermal welding. |
About US& Advantages:
1. We are the verified first and largest manufacturer of capillary mats with a tradition of over 15 years
2. We use only the best quality PPR raw material with more outstanding performance!
3. All the sinolanc mats are produced on special advanced machines in strict accordance with quality standards.
Every working step in the manufacturing process is monitored and recorded
4. Sinolanc mats have exported to 50 countries and established distributors in some European countries
and working with experienced installers can provide efficient technical and construction support overseas.
Such as Poland, Germany, Romania, Slovakia, Latvia, Lithuania, Netherlands, Switzerland, Italy, etc.
Heating&Cooling System Installation
With the advantage of good flexibility,the sinolanc capillary tube mats can be installed on roof, wall, floor, under the surface decorative materials. They used in new buildings and refurbishment of various types of buildings.
For cooling purposes, sinolanc capillary tube mats are preferentially installed either in or on the ceilings.
They can be integrated into walls of various designs and used as wall heating and wall cooling.
Underfloor heating systems with capillary tube mats can be used for temperature control in all buildings. They are either integrated into an existing screed or laid directly on an existing floor as a thin-layer underfloor heating system and enable gentle temperature control of floor surfaces.
Energy Solutions
Application
1. Capillary tube mat can be used as independent humidity control air conditioning systems.
2. Capillary tube mat can be used to make air conditioning wall (also called gravity cycle air conditioning system), which is easy to adjust the temperature and humidity.
3. Capillary tube mat can be used for heating to replace the traditional radiator and common floor heating system, which is easier to install and has high efficiency.
4. Capillary tube mat can be used in agricultural greenhouse. Using the regenerative capacity of the soil, it can help to balance the temperature difference and improve the production efficiency.
Capillary tube mat can be made as the heat collector of the water resource heat pump, which can also be used to collect the residential heat of industrial waste water, can recycle the renewable resources.
Our Services
We can provide you with below services for freely! Welcome to contact me!
1. Product quotation(sample order is acceptable);
2. Model selection and economic solution suggestion;
3. Technical or installation support in domestic and overseas.
4. Transportation proposals and freight quotation;
24hours on whatsapp for quick reply. +86 18920696269(MOON SHI)
