Factory Price Minus Degree Low Temperature Meter for Charpy Impact Test Usage CDW
US$ 3000 - 15000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T L/C
- 15 days
You May Like
-
Climate Chamber / High-low Temperature Test Chamber / Environmental Chamber for Impact Test
-
Impact Testing Machine Usage Charpy Impact Test Low Temperature Cooling Device CDW-40
-
Charpy Impact Test Cooling Chamber for Cooling Charpy Sample CDW-40/60/80/100/196
-
Pendulum Charpy Impact Testing Usage Cooling Chamber CDW Series Low Temperature Chamber / Metal Testing Equipment
-
Impact Testing Low Temperature Meter CDW Series Double Refrigerating Compressor Charpy Low Temperature Cooling Tank
-
Pendulum Impact Testing Low Temperature Chamber Low Temperature Tank Price Impact Low Temperature Device
Product Details
| Brand Name | Liangong | Place of Origin | China | |
| Model Number | CDW-40/60/80/100/196 | Power | Electronic | |
| Usage | Impact Testing Machine |
Product Description
Usages and characteristics:
1.CDW-type low-temperature impact testing meter is the compressor refrigeration of the latest research and development in accordance with cooling requirement of GB/T 229-2007 "Metal Charpy Gap Impact Test Method".
2.This equipment used cascade compressor refrigeration technology, the use of the principle of heat balance and mixing method of circulation to achieve uniformity of the sample auto-cooling and temperature, to fully meet the temperature indicators of national standard GB/T229-2007, EN10045-2, E23-02A of the provisions.
3.The equipment is simple, convenient and efficient for working, which is the ideal equipment of specimen cooling and insulation for low-temperature impact testing. At the same time, it can also be used for other low-temperature detection and testing.
Main technical parameters
| Specifications | CDW-40 | CDW-60 | CDW-80 | CDW-80T | CDW-100(110)T | CDW-196 |
| Temperature range | Room temperature ~-40°C | Room temperature ~-60°C | Room temperature ~-80°C | Room temperature ~-100(110)°C | Room temperature ~-196°C | |
| Temperature control accuracy | ±0.5°C | ±2°C | ||||
| Cold room volume | 275*160*120mm | |||||
| Dimensions(mm) | 910*510*920 | 710*600*740 | 1300*800*1000 | 710*600*740 | ||
| Box material | Iron Spray | Stainless steel | Iron Spray | Stainless steel | ||
| Specimen quantity | No less than 60 | |||||
| Mode of refrigeration | Compressor refrigeration | Liquid nitrogen refrigeration | ||||
| Cooling medium | Ethanol or other unfrozen liquid | Liquid nitrogen | ||||
| Power | 1.8kW | 2.3kW | 2.5kW | 3kW | 100W | |
| Remarks: The cold room volume can be specially manufactured according to the customers requirement. | ||||||
