2RK6GN-C/2GN-100 1200 rpm 220v AC Voltage electric motor with reducer
General information of motors, for IK, RK, TK type
General information of reducers, for GN, RK, GU type
Reversible Motor |
Force |
Peripheral Wave |
Voltage |
Current |
Starting torque |
Rated Torque |
Rated speed |
Capacity |
Resistance Voltage |
2RK6GN-C |
10W |
50Hz |
220V |
0.12A |
600 gcm |
487 gcm |
1200 rpm |
0.8uF |
500V |
External dimension
Torque Table (Kg / cm × 9.8 ÷ 100) = N · M (Nm)
Tabulated figures are based on the rotational speed of motor synchronized operation, in the case of the rated load actual output speed for synchronous operation speed of about 80% to 90%. Light gray statements are the same as the running direction of the output shaft Rain motor steering, white column indicates the the output direction Rain motor shaft turn in the opposite.
