Intelligent PID Temperature Controller Alarm SSR White Display

Intelligent PID Temperature Controller Alarm SSR White Display photo-1
Intelligent PID Temperature Controller Alarm SSR White Display photo-2
Intelligent PID Temperature Controller Alarm SSR White Display photo-3
Intelligent PID Temperature Controller Alarm SSR White Display photo-4
Intelligent PID Temperature Controller Alarm SSR White Display photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2010
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
XMT7100 intelligent PID temperature controller alarm SSR white display
Product Description
· Small size, high performance, full input, especially suitable for temperature control system of small equipment · Thermal resistance and thermocouple are compatible with 10 temperature signals, with high precision and fast response · Five control modes are optional · PID self-tuning function, automatically adapt to controlled objects · The meter can display temperature in degrees Celsius or Fahrenheit
Specification
· Power supply: AC/DC85 ~ 260V(other power supply can be customized) · Input signal: thermocouple :T, R, J, B, S, K, E, WRE3-WRE25, thermal resistance :Pt100, Cu50 Overall power consumption: less than 2W · Sampling rate: 4 times per second · Display color: red LED (other colors can be customized) · Display range: full range of input signals · Precision: 0.2% FS±1 word · SSR level: DC 8V/30mA · Contact capacity: AC250V/3A; DC24V/5A · Service environment: 0 ~ 50℃; 85% RH or less
Packing & Delivery
carton
