Product Description
OralTop-Series Oral Thin Film making machine is specially designed and manufactured for making medicine film on paper, plastic film, metal film,etc. The active ingredient can be either dissolved or suspended in the polymeric matrix. OralTop-Series is used for making roll type Oral Thin Film.Oral Thin Films with systemic activity for rapid delivery. An Oral Thin Film (OTF) is a very thin film, composed of a mono or multi-layer polymeric matrix, which is applied in the mouth. OTF are often water based soluble polymers designed to rapidly deliver drugs systematically.
Feature:
1.Coating thickness from 40 – 1000 microns wet.
2.High coating accuracy.
3.Individual temperature adjustment zones.
4.Recording of all process related parameters.
5.Variable speed of base film.
6.Uniform air flow throughout the machine.
7.cGMP Construction.
8.Liquid dosing system with peristaltic pump.
9.Thickness checking or wet & dry film.
Model | OralTop-300 |
Max.Production Width | 300mm |
Max. Line Speed | 10m/min (depend on medicine) |
Drying/Heating Method | Stainless Steel Heat Exchanger |
Temperature Range | 20-150℃ |
Total Power | 18kw |
Power Supply | 380v 50hz three phase or 220v 50hz three phase |
Overall Dimension | 2700*1200*2300mm |
Product Contact Parts Material | SS316L |
Control System | PLC and Touch Screen control |
Machine Frame Material | SUS304 |
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us.
