Automatic Tablet Capsule Candy Coffee Bean Electronic Intelligent Photoelectric Filling Counting Machine Production Line
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2012
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Fresh Food Fruit Vegetable Meat Vacuum Pillow Packing MachineNegotiableMOQ: 1 -
Bread Sorting Line Bag Biscuit Box Food Automatic Pillow Packing Machine LineNegotiableMOQ: 1
-
Bread Pastry Biscuits Steamed Buns Nitrogen-Filled Pillow Food Automatic Packaging MachineNegotiableMOQ: 1
-
Automatic Lemon Orange Navel Orange Pillow Fruit Packing MachineNegotiableMOQ: 1
-
Automatic Nitrogen Inflatable Multifunctional Bread Food Pillow Packaging MachineNegotiableMOQ: 1
Attention:
1.All prices and parameters shown above are automatically generated by the system, if you want to know the exact
information, please click "Contact Supplier" to send mail to us.
2.Because of the time difference, we suggest that you can choose to send us an inquiry instead of online chat.
3.When sending us an inquiry or message, please tell us your Email or WhatsApp/Wechat/Skype .etc, then our sales manager can contact you quickly.
information, please click "Contact Supplier" to send mail to us.
2.Because of the time difference, we suggest that you can choose to send us an inquiry instead of online chat.
3.When sending us an inquiry or message, please tell us your Email or WhatsApp/Wechat/Skype .etc, then our sales manager can contact you quickly.
Equipment introduction
01.Bottle Ordering machine
The machine adopts special mechanism (compressed air is not needed) to arrange disorderly bottles and keep their mouths upwards when they are delivered downstream. If the next working procedure lacks bottle, the unscramble machine will continue working to ensure working continuity. If bottles are jammed in the next working procedure, the machine will stop automatically. The machine has the function of photoelectric inspection to ensure reliable and smooth running. If bottle size is changed, you only need adjust width of bottle conveying lane and relevant template. It is easy to operate, so generally operators can master. The product conforms to requirements of GMP.
Size of bottles |
20-300 ml |
Output |
40-100 bottles/min |
Power supply |
220V 60Hz |
Power |
0.15KW |
Overall dimension |
950*950*1110mm |
02.LTEC-24 Automatic Electronic counting machine
This machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc. The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen operation and PLC Control for convenient running.
Conveyor Belt
Blanking
Feeding Mouth and Stop Cylinder
Material: Stainless Steel 304
Sensor Control Board
Adopts Imported Brand Sensor Accurate, high speed and efficiency
Vibrating Guide Way
It adopts 3-section electromagnetic Vibrator, frequency is variable and adjustable, to separate counting objects fast.
Model Name |
LTEC-24 |
Hopper Volume |
60L |
Capacity |
90 bottles(30 pcs/bottle)/min |
Filling Quantity |
15-9999pcs/bottle (adjustable) |
Bottle Size |
Diameter: 30-75mm Height:40-250mm |
Counting Size |
Thickness: 3-10mm Diameter: 3-15mm Length: 3-30mm |
Compressed air |
0.5Mpa |
Conveyor Belt Length |
2400mm |
Machine Weight |
500kg |
Machine Size L × W × H (mm) |
2000*1600*1680mm |
03.Desiccant Inserting Machine
The machine applies automatic controlling system to take the place of the previous manual operation. The machine can automatically cut the belted desiccant and insert the desiccant bag into the container accurately and speedily.
It is available for bottles and pots made of different materials. It features double-lane photoelectric positioning, intelligent feeding length controlling and automatic adjustment of accumulated length error.
The electronic controlling system ensures the machine starts when bottles reach working position and stops when bottles are insufficient automatically. The product conforms to the requirements of GMP completely.
Bottle Size |
20-300ml |
Output |
40-100bottles/min |
Power Supply |
220v 60Hz |
Power |
0.85kw |
Overall Dimension |
1250*630*1750mm |
04.LTCG-160 Capping Machine
The bottle caps neatened by the cap neatening device ,the bottle caps with mouth up are carried to the caps collecting guideway, the bottles come from other equipment of the assembly line enter the caps collecting area. The bottles move ahead with clamping of the two sides clamping device then the caps match the bottles automatically. The cap pressing device press the caps to the pre-tight situation before rotating the caps. Under the function of three pairs of high speed rotating wearable rubber wheels, the caps match with the bottles tightly.
Features：
1.Strong compatibility ,suitable for various sizes of cap shape、bottle shape.
2.A pair of cap dropping and wearing device suit for all kinds of bottle caps.
3.Cap unscrewing torque control, ensure the quality of the screw cap (optional)
4.Oscillating swivel wheel, strength is more suitable, greatly reduce the swivel wheel wear
5.No bottle or cap ,no work .By testing, it will wipe out the skew、inverse caps and caps without aluminium foil .It has the function of fault self examining and any other check warning control functions ,so it can ensure the continuity and accuracy
6.Operate automatically ,intelligently control with the last and next process, with good Harmony .Special operating person is not necessary so it can save labor cost.
Applicable bottle shape |
20～500ml of round、oblate、square、flat square bottle |
Capacity |
50～120 bottles per minute |
Cap size |
φ25-φ50mm |
Machine Size |
1850×600×1560mm |
Weight |
600kg |
Power supply |
AC220V 50Hz1.8kw |
Air pressure |
0.6Mpa |
05.LTLF-1 Automatic Induction Aluminum Foil Sealing Machine
Intermediate frequency power supply of the machine makes effective output power great and output current adjustable. It also auto tracks change of current load and makes adjustment in time. The machine is available for various bottles. The special sealing induction plate is completely shielded without electromagnetic pollution and its safety is superior to high-frequency power supply.
Coding system of the machine adopts built-in water circulation to save water consumption and reduce water pollution; it also has pressurizing system which features good cooling conditions, short sticking time, firm sealing and high stability.
Bottle Size |
20-300ml |
Output |
50-120bottles/min |
Diameter of caps |
Smaller than 60mm |
Height of bottle |
220mm |
Power Supply |
220V 60Hz |
Power |
2Kw |
Overall Dimensions |
1300*780*1750mm |
06.MT-200 Labeling machine
MT-200 Labeling machine in order to achieve rationalization of production target and design. The machine comes with automatic labeling process, simple operation, high speed running, accurate labeling position, beautiful labeling.
The machine can be used or pharmaceutical, chemical and foodstuff Industry labeling.
