Custom NJP-2500C Fully Automatic Capsule Making Machine 00#-5# Hot Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2012
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DPP-320F Tablet Capsule Blister Packer Blister Packaging Machinery Tropical Blister Packing MachineNegotiableMOQ: 1 -
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging MachineNegotiableMOQ: 1
-
DPP-250A Blister Packing Machine Blister Packaging Machinery Blistering Machine for Tablets CapsulesNegotiableMOQ: 1
-
Automatic Bullet Shape Suppositories Suppository Filling and Sealing MachineNegotiableMOQ: 1
-
DPP-80 Blister Packing Machine ManufacturerNegotiableMOQ: 1
Product Description
Applications:
NJP-1000/1200 adopt PLC control system, human-machine interface, when running malfunction or lack of stuff, automatic alarm, malfunction display, automatic dismiss alarm. And with functions of password setup, touching screen display, automatic parameter setup, data printing, reset, etc.
The jump-start axed, cam and other main damageable parts all adopt imported materials. And the machine is suitable for Powder, Granular and Pellet filling, one hour for 12,000/24,000capsules, special for Capsule size from00# to 5#.
Characteristics:
1.It has been improved the inner design turret, and imports beeline bearings for each machine from Japan directly, so that it can be sure a longer usage-life and precision of machine.
2.The working station cam runs under the good lubricating condition, and maintains the inner lubrication of cam slot to a full extent, increasing the pressure pulverization oil pump, thus extends the operation life of the spare parts.
3.It adopts enlarged Cam, LTPM CHINA has become the one who matches the cam of RU100 to Ru83, while it enhances the stability of the machines and extends the life of the machines to a great extent.
4.It is controlled by the computer, has a stepless timing with the frequency-conversion, the numeral showing makes an easy operation and clear appearance.
5.Adopt Plane Spring for filling powder, this type spring can afford TWO BILLION TIMES Pressing, but never changed overall dimension. So it makes the Weight of Powder filling in an accuracy number.
6.Automatic Capsule Switch operated by Touch Screen avoid Dangerous Accident happens when open the switch by hand into the working station.
7.Our quality machine use Tanshing Cam box, in automatic capsule filling machine area Honest Business is the most important, Because Customers can’t see the mechanical parts inside. So our company can promise we use the real type but never “labeling type”.
8.The multi-bore dosing brings a precision dosage (it is controlled around ±0.75%); the good capsule applicability makes a higher capsule qualified rate (≧99%).It can be filled with the Chinese traditional medicine and the Western medicine.
9.Add the extra function of capsule control switch. (Control the capsule outside of the machine; it is more safely and quickly).
10.Add the click-moving control system, makes an easier operation and clearness.
Technical Parameters
Model: | NJP-1000 | NJP-1200 | ||
Capacity: | 1000capsules/min | 1200capsules/minute | ||
Machine suitable for: | capsule Size #00 to 5 | |||
Power supply: | 415v 50Hz three phase (it can be changed depend on your requirement) | |||
Power consume: | 3.2kw | 5.5kw | ||
Quantity of mould bores: | 8pcs | 9pcs | ||
Noise standard: | ﹤75dB(A) | |||
Weight: | 1000kgs | 1000kgs | ||
Overall dimension: | 1020*870*1980mm | 1020×870×1980mm mm | ||
Machine main body is made from S.S 304 Electric motor: Sew-Germany | ||||
Product Details
More Products
Company Profie
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us.
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us.
