Industrial Kiwi Powder Spray Drying Machine Processing Line
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Coffee Powder Spray Drying Production Line Suitable For Spray Drying Of Pharmaceutical Wall Materials
-
ZP-31D High speed tablet press machine pill with GMP standard for pharmaceutical
-
Large Capacity Commercial Food Freeze Dryer Equipment Machine
-
ZP-Series Professional Rotary Salt Block Camphor Candy Pill Press Tablet Making Machine
-
LPG-Series Hot Sale Spray Dryer Machine With GMP Standard
-
LTDG-Series Vacuum Food Freeze Dryer Price With High Efficient
Product Description
Product Description
The spray machine for drying is the technology most widely used in the liquid technology shaping and in the drying industry. The drying technology is the most suitable for producing solid powder or particle products from liquid materials, such as: solvent, emulsion, suspension and pumpable paste states, fro this reason, when the particle size and distribution of the final products, residual water contents. Mass density and the particle shape must meet the precise standard, spray drying is one of the most desired technology.
Features
1.Rapid drying speed, which just takes 5-15 seconds.
2.Suitable for thermo-sensitive material and keep the origin state.
3.Simple processing and easy operation, which is suitable for continuous production.
4.The product has a good degree of uniformity, liquidity and dissolubility with high quality and purity.
5.Can adjust the product diameter, density and water content in some degree which is convenient to control and manage.
Technical Parameters
Model | 5 | 25 | 50 | 100 | 150 | 200-2000 | |||||
Inlet temperature | 350°C | ||||||||||
Outlet temperature | 80-90°C | ||||||||||
Max. evaporation(kg/h) | 5 | 25 | 50 | 100 | 150 | 200-2000 | |||||
Centrifugal spraying nozzle transmission mode | compressed air transmission | mechanical transmission | |||||||||
Rotation speed (r.p.m) | 25000 | 22000 | 21500 | 18000 | 18000 | 15000 | |||||
Spray disc diameter | 50mm | 100mm | 120mm | 140mm | 150mm | 180-340mm | |||||
thermal source | electricity | electricity | electricity + steam, fuel, oil, fuelgas | solved by user | |||||||
Max. electric heating power (kw) | 8 | 31.5 | 60 | 81 | 99 | ||||||
Overall dimension | 1.8*0.93*2.2 | 3*2.7*4.26 | 3.7*3.2*5.1 | 4.6*4.2*6 | 5.5*4.5*7 | optional | |||||
Powder recollection (%) | 95 | 95 | 95 | 95 | 95 | 95 | |||||
Product Details
More Products
Company Profie
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your schedule in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us！
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your schedule in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us！
