Help CenterIndustrial Single Layer Mesh Convey Belt Mechanical Dryer for Alge Seaweed Cassava Fruit De-watering Vegetable Feed
Related Products
-
Low Price DW/DWT Hot Air Circulating Mesh Belt Dryer Conveyor Dryer Dehydrator for AppleNegotiableMOQ: 1 -
Best Sale Conveyor Belt Dryer Industrial Food DehydratorNegotiableMOQ: 1
-
Best Sale dw Model Continuous Algae Mesh Belt Dryer Conveyor DryerNegotiableMOQ: 1
-
Low Price Licorice Root Drying MachineNegotiableMOQ: 1
-
Best Sale Elephant Foot Yam Drying Equipment /mesh Belt DrierNegotiableMOQ: 1
Features:
• Amount of air, heating temperature, time of material stay on the belt and velocity of feeding material can be adjusted in order to obtain the best drying effect.
• Equipment's configuration is very flexible. It can use the netlike belt washing system and cooling raw material system.
• Hot air can be circularly applied, the energy is greatly saved.
• Unique air dividing device, it makes hot air distribute uniformly; this can guarantee products' quality.
• Heating source can be selected from steam, conducting heat oil, electricity, coal furnace and oil burner.
Technicals:
|
spec |
unit |
DW-1.2-8 |
DW-1.2-10 |
DW-1.6-8 |
DW-1.6-10 |
DW-2-8 |
DW-2-12 |
|
unit number |
|
4 |
5 |
4 |
5 |
4 |
6 |
|
belt width (m) |
m |
1.2 |
1.2 |
1.6 |
1.6 |
2 |
2 |
|
drying section length |
m |
8 |
10 |
8 |
12 |
8 |
12 |
|
thickness of the material |
mm |
|
|
10-80 |
|
|
|
|
temperature |
°C |
60-130 |
|||||
|
steam pressure |
Mpa |
0.2-0.8 |
|||||
|
steam consumption |
kgsteam/kgHjO |
2.2-2.5 |
|||||
|
drying strength |
kgH20/h |
6~20kg/m2 • h |
|||||
|
total power of the blower |
kW |
3.3 |
4.4 |
6.6 |
8.8 |
12 |
16 |
|
total power of the equipment |
kW |
4.05 |
5.15 |
7.35 |
9.55 |
13.1 |
17.1 |
