Factory directly supply fruit and vegetable crisp chips vacuum drying machine
Product Description
The vacuum low temperature puffing system is mainly composed of a pressure tank and a vacuum tank which is 5-10 times larger than the pressure tank. After pretreatment, the fruit and vegetable raw materials were dried to moisture content of 15%-25% (the water content of different fruits and vegetables is different). Then, fruits and vegetables are placed in a pressure tank. By heating and pressing, the evaporation and flashing of water in fruits and vegetables suddenly to achieve the purpose of expansion of fruit and vegetable cells.
Technical Parameters
Item |
Parameter |
Material |
Food grade 304 stainless steel |
Vacuum pot size |
5500*1800mm(Diameter) |
Vacuum pot plate thickness |
8mm |
Vacuum puffing pot size |
2800*1200mm(Diameter) |
Vacuum puffing pot thickness |
6mm |
Heating mode |
Steam |
Steam consumption |
160kg/h |
Vacuum puffing pot door open mode |
Manually |
Capacity |
40kg/ pot for material, total 80kg/batch |
Processing time |
According to the products |
Processing time |
According to the products |
Thermal insulation material |
Rock wool |
Thickness of insulation layer |
50mm |
Vacuum pump power |
19kw/set 1set |
Machine Detail
