Wide Range of Application Automatic Food Chocolate Coating Machine

Hangzhou SED Imp.And Exp.Co.,Ltd.
Wide Range of Application Automatic Food Chocolate Coating Machine thumbnail-1
Wide Range of Application Automatic Food Chocolate Coating Machine thumbnail-2
Wide Range of Application Automatic Food Chocolate Coating Machine thumbnail-3
Wide Range of Application Automatic Food Chocolate Coating Machine thumbnail-4
Wide Range of Application Automatic Food Chocolate Coating Machine thumbnail-5
Wide Range of Application Automatic Food Chocolate Coating Machine photo-1
Wide Range of Application Automatic Food Chocolate Coating Machine photo-2
Wide Range of Application Automatic Food Chocolate Coating Machine photo-3
Wide Range of Application Automatic Food Chocolate Coating Machine photo-4
Wide Range of Application Automatic Food Chocolate Coating Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Recommend Products
Factory Display
This product was developed based on the imported equipment in 1992 and has been placed on the list of the "Sin-tech Spark Project of Zhejiang”. In 1995, this product passed the provincial level technical appraisal of new product,was awarded the "Wenzhou Scientific and Technological Improvement Award" and also recommended as the "Brand-name and Quality High-tech Product of Zhejiang" and "National New Product of 1996". And it has been exported to such regions as Europe, Australia and Southeast Asia, etc. and can be used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film, etc. And it has such characteristics as high efficiency, low energy consumption and small floor area, etc. And it can be widely used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film etc. In such fields as of pharmaceutical, food and biological products etc.And it has such characteristics as good appearance in design ,high efficiency, low energy consumption and small floor area, etc.

The tablets make complicated and constant track movement with easy and smooth turning and frequent exchanging in the clean and closed rotational cylinder of the film coating machine. And it can automatically spray coating medium according to the process flow and reasonable process parameters. The hot air exhausted through the bottom of the tablets under the effect of air exhaust and negative pressure so as to make coating medium dry quickly on the surfaces of the tablets and form a firm, fine and close and smooth surface film.
Product Name
SED-10GB
Max. tablet volume
10 Kg / time
Sugar coating drum dia.
600mm
Feed inlet dia.
260mm
Drum speed
2-18 r.p.m
Host machine motor power
0.55kw
Exhaust cabinet motor power
1.1 kw
Hot air cabinet motor power
0.75 kw
Hot air cleanness
100000 level
Air heater temp.-adjust range
~ 80 ℃
Exhaust blower air flow
1645 m3/h
Details Images

Agitating and holding tank

Outboard discharging device

Built in discharging device

Peristaltic pump

Coating paddle

Auto air valve system

Optional CIP system

Drainage of water trough
