High Safety Level Good Performance Gloves Bottles Carton Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Excellent Performance Horizontal Bottle Toothbrush Cartoning Packing MachineNegotiableMOQ: 1 -
Simple Maintenance Automatic Tea Bag Cartoning Box Packing MachineNegotiableMOQ: 1
-
Automatic Toothbrush Blister Box Packaging Cartoning MachineNegotiableMOQ: 1
-
New Type Energy Saving Automatic Cartoning Machine Carton Box Packing MachineNegotiableMOQ: 1
-
Vertical Type Carton Box Packing Machine Automatic Electric Soap Rotary Cartoning MachineNegotiableMOQ: 1
Recommend Products
Products Description
This machine is suitable for cardboard case packaging of tabe toothpaste, ointment. and soft package ( packed condoms ). It consists of direction folding (1-4 folds) and feeding equipment,cardboard case forming and feeding, batch number printing, sealing of case tongues at both ends etc. The whole encasing process is finished automatically. It can be added hot-glue machine.
Model |
Model |
SED-120WZH-C |
|
Encasing speed |
Cartonning speed |
30-120 boxes /min |
|
Box |
Quality requirement |
250-350g/㎡【Base on carton size】 |
|
Dimension range（L×W×H） |
70-200）mm×（35-120）mm×（14-70）mm |
||
Leafle |
Quality requirement |
60-70g/㎡ |
|
Unfolded leaflet specification |
（80-250）㎜×（90-170）㎜ |
||
Fold range |
【1-4】Fold |
||
Compressed air |
Working pressure |
≥0.6mpa |
|
Air consumption |
120-160L/min |
||
Power supply |
Power supply |
220V 50HZ |
|
Main motor power |
Main power |
0.75kw |
|
Machine dimension(L×W×H) |
Overall dimension, L×W×H |
3650*1350*1750mm |
|
Machine weight |
Net weight |
1400kg |
|
Features:
1: International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.
2: Adopt human-machine operation system.
3: Automatically stop when machine is overload.
4: Automatically reject lacking of package product and leaflet.
5: Automatically display trouble, Alarm and count finished products.
6: Stable performance,operation is easy.
Details Images
