Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine

Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine photo-1
Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine photo-2
Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine photo-3
Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine photo-4
Washing Powder Making Machine/dry Detergent Powder Mixer/mixing Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1996
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

GHJ Series Vertical High Speed Mixer

Application:

1 GHJ type vertical high speed blender for mixing powder with small moisture to desigh. It is a new type high-efficiency, regular and no dead angle machine.

2 The contact parts material are all stainless steel. The stirring shaft with sealing device to avoid material swap and guarantee bearing and driving medium life.



Characteristic:

GHJ high speed blender has these characteristics as follows:

1. Use install the bottom's vertical high speed paddle formative centrifugal force impact material, let it outside upward roll and inside downward sunk like volution. Let the material inside, outside, up and down mixing and compound full.

2. Use install the parietal's high speed crushed paddle to smarsh roll material of outside, at the sametime it has disturbed function, increase material relative motion, enhance mixing result.

3. Due to two paddle's combined action, it is compound full and uniform at short time. It's efficiency is higher and other mixers are difficult to compare.

4. There are no dead angle of mix bin. It is emptying quickly and cleaning easily.

5. All contact parts of this machine are all stainless steel. When mixing the raw material will not volatilizer, go bad and run off phenomemon. It is ensure craft matching demands.

6.  The machine are suitable for different proportional dry or wet raw materials to mix. It is specially for chicken extract, medicine granule and drink powder to compound.



Technical Parameters:

Type Work volume(L) Stiring weight (KG/Batch) Installed power(KW) Weight(KG) Overall dimension (mm)
GHJ-350 350 150 7.37 600 1500×1090×1200
GHJ-400 400 200 8.07 650 1500×1090×1300
GHJ-850 850 400 10.87 850 1718×1320×1400

 Notes: According to customers' requirement, we may design non-standard type machine.
