ZAPI Handset ZAPI_HHC

Name: ZAPI Handset ZAPI_HHC
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Detailed Images

SPECIFICATIONS:

This handset (handheld programming unit) is not the product of ZAPI company. It is developed and manufactured by a Chinese manufacturer. This handset works with most ZAPI motor speed controllers (typical application: ZAPI H2B DC series winding motor speed chopper). For more details, please feel free to contact us.

ZAPI controllers all have a serial output that is able to communicate with the external systems, such as personal computers. Designed as an intelligent microprocessor based console, with a LCD display and multi-function keyboard, the handset ZAPI_HHC is developed for monitoring, diagnosing and programming the ZAPI controllers.

Product Description

Technical details:

PROGRAMMING PARAMETERS:
maximum current
braking
acceleration rate
creep speed
1st level of speed reduction
2nd level of speed reduction
etc.

TESTER: provides a visual display of analogue and numeric measurements within the chopper (battery voltage, motor voltage, motor current, temperature, throttle signal, etc.).

RESTORE: enables a fast digital re-coverage of previously set parameters. This function may be used for reprogramming controllers to obtain the homogenized operating behavior.

ALARMS: this function displays visually the last 5 controller faults.

DIMENSIONS: 100 x 190 x 60 mm

Packing & Delivery

Package:Normally we use the standard exporting packaging. We also can according to clients' request .

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperating.
2. By Air: Delivery from the Shanghai airport to customer's destination city air port.
3. By Sea: Delivery from the Shanghai sea port .

Our Company

Hefei Huanxin Technology Development Co., Ltd. has been devoting ourselves to developing and manufacturing and other since 2004. We are located in Hefei, Anhui Province, with convenient transportation access. We employ over 101 - 200 People staff members. We have achieved great improvement since our company was founded in 2004. We abide by the motto of Firstclass quality, Reasonable price, Best service and Professional product support.
