High Quality Designed Curtis 1313-4331 Handheld Programmer

Name: High Quality Designed Curtis 1313-4331 Handheld Programmer
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

High Quality Designed Curtis 1313-4331 Handheld Programmer

Product Description

Product Name	Curtis Handheld Programmer
Function	Program Controller
Package	Carton/Package

Product performance description

* OEM level programmer: full programming function
* Operating ambient temp. range: -20°C to 50°C (-4°F to 122°F)
* Storage ambient temp. range: -40°C to 85°C (-40°F to 185°F)
* Package environmental rating: IP53 (with programmer cable plugged in and SD-card cover closed)
* Dimensions (L×W×H): 190 × 100 × 36 mm (7.5" × 3.9" × 1.4")
* Weight: 0.27 kg (0.6 lb)
* Regulatory compliance: CE/RoHS

KEY FEATURES

* Direct access to applicable Curtis motor speed controllers via CANopen network.
* Fully compatible with Curtis next gen F series and all existing 1313 programmable motor speed controllers.
* Large high resolution color display shows multiple parameters simultaneously for quick adjustment.
* Backlight for easy viewing in low-light environments.
* Cloning feature and 64 Mb internal memory allows multiple parameter files to be stored in the Handheld Programmer, making it
easy to transfer settings to other vehicles.
* Advanced troubleshooting capabilities for all vehicles that use Curtis programmable motor controllers or control systems.
* AA Battery compartment allows programs to be edited without having to be connected to a system.
* Multiple language support includes English, German, Spanish, French, and Italian.
* Monitoring function allows real-time viewing of controller activity.
* Icon based graphical user interface allows for quick and intuitive menu navigation.
* Dedicated buttons for “help” and “favorites” provide for direct access to commonly used features.
* Comprehensive help text offers solutions and information at the touch of a button.
* Easily upgradeable via USB to ensure compatibility with future products and features.
* The Model 1313 programmer is easily portable, with a tough rubber protective perimeter strip.
* Programming kit comes complete with handheld programmer, Molex cable, zippered case, CANopen network DB-9 cable (where
applicable), quick start guide.

Details Images

Overview

The new Curtis 1313 handheld programmer is a powerful and intuitive programming and diagnostic tool. Model 1313 enables parameter
files to be created and edited online or offline, transferred to another controller for cloning, or saved onto a PC or SD card.
The Model 1313 performs comprehensive programming and troubleshooting tasks for all vehicles that use Curtis programmable motor
controllers or control systems.
There are four access levels:
* 1313-4331 OEM programmer
* 1313-3231 Dealer programmer
* 1313-2131 Service programmer
* 1313-1131 User programmer

The CURTIS 1313 handheld programmer supports multiple languages: English, Deutsch, Français, Italiano, or Español.
