Curtis OEM Level Handheld Programmer With 4-Pin Moles Cable/Square Plug 1313k-4331

Specifications:

• OEM level programmer: full programming function
• Operating ambient temp. range: -20°C to 50°C (-4°F to 122°F)
• Storage ambient temp. range: -40°C to 85°C (-40°F to 185°F)
• Package environmental rating: IP53 (with programmer cable plugged in and SD-card cover closed)
• Dimensions (L×W×H): 190 × 100 × 36 mm (7.5" × 3.9" × 1.4")
• Regulatory compliance: CE/RoHS

Overview:

The CURTIS 1313 handheld programmer is used to configure CURTIS motor control systems. With the programmer, you can adjust and save parameter settings, monitor real-time data, and perform diagnostics and troubleshooting.

The CURTIS 1313 handheld programmer is a powerful and intuitive programming and diagnostic tool. It enables parameter files to be created and edited online or offline, transferred to another controller for cloning, or saved onto a PC or SD card.

Key Features:

• Large high resolution color display shows multiple parameters simultaneously for quick adjustment.
• Backlight for easy viewing in low-light environments.
• Cloning feature and 64 Mb internal memory allows multiple parameter files to be stored in the Handheld Programmer making it easy to transfer settings to other vehicles.
• Advanced troubleshooting capabilities for all vehicles that use CURTIS programmable motor controllers or control systems.
• AA Battery compartment allows programs to be edited without having to be connected to a system.
• Multiple language support includes English, German, Spanish, French, and Italian.
• Monitoring function allows real-time viewing of controller activity.
• Icon based graphical user interface allows for quick and intuitive menu navigation.
• Dedicated buttons for “help” and “favorites” provide for direct access to commonly used features.
• Soft Keys (located under the LCD) change function as indicated by screen text to provide quick access to the most commonly used functions.
• Comprehensive help text offers solutions and information at the touch of a button.
• Easily upgradeable via USB to ensure compatibility with future products and features.
• The Model 1313 programmer is easily portable, with a tough rubber protective perimeter strip.
• Programming kit comes complete with handheld programmer, Molex cable, zippered case, quick start guide.

Pictures:

Package: Normally we use the standard exporting packaging. We also can according to clients' request .

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperating.
2. By Air: Delivery from the Shanghai airport to customer’s destination city air port.
3. By Sea: Delivery from the Shanghai sea port .

 Hefei Huanxin Technology Development Co., Ltd. has been devoting ourselves to developing and manufacturing and other since 2004. We are located in Hefei, Anhui Province, with convenient transportation access. We employ over 101 - 200 People staff members. We have achieved great improvement since our company was founded in 2004. We abide by the motto of Firstclass quality, Reasonable price, Best service and Professional product support.

 Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?
A: Sample needs 3-5 days.

Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
    Secondly We quote according to your requirements or our suggestions.
    Thirdly customer confirms the samples and places deposit for formal order.
    Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.

Q8: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
