Turbomolecular Pump High Quality Vacuum Pump photo-4
Turbomolecular Pump High Quality Vacuum Pump photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2016
Annual Export Value:
Below US$1 Million
Contact Supplier Request Quote Chat Now
Labfirst Scientific Instruments (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Description
A rotary vane pump is a positive-displacement pump that consists of vanes mounted to a rotor that rotates inside a cavity. In some cases these vanes can have variable length and/or be tensioned to maintain contact with the walls as the pump rotates. It can endure short periods of dry operation, and are considered good for low-viscosity fluids.
UV series rotary vane vacuum pump offers an excellent ultimate with good pumping speeds as well as superior vapour handling capabilities and quiet operation. It is usually used with distillation, evaporation, reaction equipment.

-Advanced technology to keep high ultimate pressure with gas ballast on -up to 63 CFM / 25L per second -Designed with rational structure, safety and reliability -With high flow rate, high ultimate pressure and low noise level -Free of oil leakage and easy for maintenance -Adopts KF series flange for joint with exhaust sheath to prevent any infiltrating during operating
Model
UV-10
UV-15
UV-45
UV-63
Pumping Speed (50Hz, L/s)
4
6
18
25
Open Gas Ballast, Partial Pressure (pa)
4X10 -2
4X10 -2
4X10 -2
4X10 -2
Open Gas Ballast, Total Pressure (pa)
4X10 -1
4X10 -1
4X10 -1
4X10 -1
Closed Gas Ballast, Partial Pressure (pa)
1. 2
1. 2
1. 2
1. 2
Closed Gas Ballast, Total Pressure (pa)
3
3
3
3
Rotate Speed (50Hz, rpm)
1400
1420
1440
1440
Motor Power (kw, 1-phase/3-phase)
0.55/0.4
0.75/0.75
/2.2
/2.2
Oil Capacity (L)
1.1
1.8
5
5.5
Air Inlet Diameter
25KF
25KF
DN 40KF
DN 40KF
Air Outlet Diameter
25KF
25KF
DN 40KF
DN 40KF
Noise（dB, Open Gas Ballast）
≤50
≤53
≤60
≤62
Working Environment (℃）
8-40
8-40
8-40
8-40
Weight（kg)
≤26
≤38
≤85
≤90
Dimension(W x H x D mm)
535 x 161 x 252
535 x 200 x288
730 x 280 x 410
785 X 280 X 410
EV-series rotary vane vacuum pumps are designed for reliable long time continuous operation. They have a balance between low cost and high performance.

-light weight, low cost, compact design, low noise -up to 20 CFM / 8L per second -Check valve to prevent oil back-flow -Internal oil cycling system -Gas-ballast valve to fill the exhaust space
Model
EV-5
EV-10
EV-20
Pumping Speed (L/s)
2
4
8
Ultimate Vacuum,Open Gas Ballast (Pa)
≤6×10-2
≤6×10-2
≤6×10-2
Ultimate Vacuum,CloseGas Ballast (Pa)
≤1.33
≤1.33
≤1.33
Rotary Speed (rpm, 50Hz)
1400
1400
1410
Power Required (Kw)
0.37
0.55
1.1
Voltage (V)
110v/220V
110v/220V
220V
Inlet Port Diameter (mm)
25
25
40
Temperature Rise of Pump Oil (℃)
≤45
≤45
≤65
Oil Capacity (L)
0.8
0.1
2.5
Dimension (LxWxH mm)
488x145x280
528x145x280
575x172x350
Weight (kg, with3-phase motor)
20
23
48.5

WVP-series water aspirator vacuum pump uses water to pull a vacuum. No oil is required. Each vacuum port pulls vacuum separately allowing for either two separate applications or connect them together for double the vacuum. This pump can also be used to re-circulate water through the back ports if needed.

- All major valves and parts made of PTFE - Corrosion-resistant, non-polluting - Cyclically use water to reduce the water consumption - Be a vacuum pump or circulating pump - Novel appearance, easy to operate - Low noise, stable performance
Model
WVP-02
WVP-05
Electric Power (w）
180
370
Circulating Pump
Rate (L/min)
60
90
Lift (m)
6
12
Body Material
Body Material
Corrosion Resistant
As a vacuum pump
Pumping Rate（ L/min）
10 x 2
10 x 5
Maximum vacuum
0.098Mpa (735mmHg, 0.98bar, 735Torr)
Reservoir Volume (L)
15
50
Vacuum Port (pcs)
2
5
As a circulation pump
Circulating Water Temp. (℃)
0~25
Voltage
110/220V single satge
Safety Protection
A check valve to prevent backflow
Shell Materail
PVG Surface Electrostatic Spraying
Castor
None
4
Dimension (WxHxD mm)
385×285×420
450×340×870
Weight (kg)
15
37
Warranty
One Year
A diaphragm pump is a positive displacement pump that uses a combination of the reciprocating action of a rubber, thermoplastic or Teflon diaphragm and suitable valves on either side of the diaphragm (check valve, butterfly valves, flap valves, or any other form of shut-off valves) to pump a fluid.
Model
GM-05B
GM-10
GM-20
Pumping Speed (L/min)
30
60
120
Ultimate Pressure Vacuum (Mpa)
≥0.095
≥0.08
≥0.08
Motor Power (w)
160
160
300
Inlet Diameter (mm)
φ6
φ6
φ9
Outlet Diameter (mm)
Silencer
φ6
φ9
Working Temp( ℃)
7-40
Function
Vacuum
Vacuum & Pressure
Pump Head
2
2
2
Voltage
230Vac, 50/60Hz
Temp. of the Body（℃）
<55
<55
<60
Weight (Kg)
9
10
20
Diaphragm Valves
NBR
Dimensions (L x W x H mm)
300x120x235
300x160x235
390x150x250
Diffusion pump is a practical vacuum equipment to seal the pumped vessel and remove all kinds of gases which have no chemical reaction to the working fluid in the high vacuum system. It uses a high speed jet of vapor to direct gas molecules in the pump throat down into the bottom of the pump and out the exhaust. It is widely used in both industrial and research applications. Most diffusion pumps use silicone oil or polyphenyl ethers as the working fluid.

-A high pumping speed of 80L/sec -Compact design makes it easier to integrate into space-constrained devices -Air-cooling design, no water need -Higher pumping speeds, throughput and tolerance fore-pressure -Excellent back-streaming characteristics -Low ultimate pressure, long-term reliability
Turbomolecular pump is a type of vacuum pump, superficially similar to a turbopump, used to obtain and maintain high vacuum. These pumps work on the principle that gas molecules can be given momentum in a desired direction by repeated collision with a moving solid surface. In a turbomolecular pump, a rapidly spinning fan rotor 'hits' gas molecules from the inlet of the pump towards the exhaust in order to create or maintain a vacuum.

- Exceptional pumping speeds (600L/s) and compression ratios - Huge install base of turbopumps with proven reliability - Individual intelligent controller with built-in protections - Fully end user serviceable - Extended lifetime and low cost
