Turnkey Glass Short Path Wiped Film Evaporator Molecular Distillation Equipment
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2016
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Glass Rolled Continuous Short Path Crude Wiped Film Evaporator Distillation Molecular DistillerNegotiableMOQ: 1 -
Glass Wiped Film Distillation Molecular Distillation MachineNegotiableMOQ: 1
-
Continuous Processing Molecular Distillation SystemNegotiableMOQ: 1
-
Turnkey Good Price Lab Glass Evaporator Wiped Thin Film Molecular Distillation EquipmentNegotiableMOQ: 1
-
Turnkey Short-range Glass Molecular Distillation ApparatusNegotiableMOQ: 1
Lab1st Glass Wiped Film Distillation Unit
Molecular (wiped film) distillation is the best thermal separation machine for heat-sensitive material because it is the gentlest type, causing the least amount of thermal degradation of product. It is a process of separation, purification and concentration of natural products, complex and thermally sensitive molecules. Lab1st molecular distillation units are wildly used for purification of oils, such as herb oil, garlic oil, cod liver oil in chemical and pharamaceutical industries.
In the system, material is delivered from a feed flask into a cylindrical evaporation section, having heating on the outside and a diagonally slotted wiper mechanism forcing liquid around and downward in a thin film on the inside. In the center of the body is a closely positioned internal condenser, providing a short path for vapor molecules traveling from the heated surface to the condenser surface.
Lab1st molecular distillation units have three series (glassware, stainless steel or hybrid) with different throughput for
yourchoices, from 0.5kg/hr up to 250kg/hr. In addition to the single stage systems, we also offer multi-stage systems to improve your working efficiency.
The whole molecular distillation system includes supporting chillers, heaters, vacuum pumps and all accessories. Some popular units are in stock at our USA warehouse.
In the system, material is delivered from a feed flask into a cylindrical evaporation section, having heating on the outside and a diagonally slotted wiper mechanism forcing liquid around and downward in a thin film on the inside. In the center of the body is a closely positioned internal condenser, providing a short path for vapor molecules traveling from the heated surface to the condenser surface.
Lab1st molecular distillation units have three series (glassware, stainless steel or hybrid) with different throughput for
yourchoices, from 0.5kg/hr up to 250kg/hr. In addition to the single stage systems, we also offer multi-stage systems to improve your working efficiency.
The whole molecular distillation system includes supporting chillers, heaters, vacuum pumps and all accessories. Some popular units are in stock at our USA warehouse.
What is Molecular Distillation System?
Specification
Lab1st GMD- A series Molecular Distillation Unit Data Sheet | ||||||||||
Model | GMD-100A | GMD-150A | GMD-200A | |||||||
Throughput（L/h） | 0.5~1 | 1.25~2 | 1.75~3 | |||||||
System's Vacuum（Pa） | ≤0.1Pa（no load） | |||||||||
Agitate Motor Speed（rpm） | ≤400 | |||||||||
Sealing Standard | Food grade fluororubber | |||||||||
Framework | Stainless steel frame with universal casters | |||||||||
Power | 220，1P（customizable） | |||||||||
Installation Dimension | 1500*628*1750 | 1730*628*2000 | 1980*628*2050 | |||||||
Certification | CE (Available as UL certificated or UL compatible) | |||||||||
Main Evaporator | Evaporation Area（㎡） | 0.1 | 0.25 | 0.35 | ||||||
Material | High borosilicate glass | |||||||||
Temperature Range （℃） | RT~250℃ | |||||||||
Internal Condenser | Material | High borosilicate glass | ||||||||
Type | Cooling coil type | |||||||||
Wiper System | Type | Centrifugal scraper | ||||||||
Scraper Material | PTFE | |||||||||
Motor | Magnetic stirring | |||||||||
Cold Trap | Material | High borosilicate glass +PVC | ||||||||
Receiving Bottle Volume（L） | 1 | |||||||||
Cooling Circulator | Optional | |||||||||
Feeding system | Feeding Pump | Type | Peristaltic pump | |||||||
Speed（ml/min） | 0~720 | |||||||||
Preservation | Heating tape +PT100 | |||||||||
Preservation temp（℃） | RT~100℃ | |||||||||
Feeding Tank | Volume（L） | 2 | 3 | 5 | ||||||
Jacket Volume（L） | 1.5 | 1.8 | 2 | |||||||
Collection for Light Conponents | Heat Preservation | Heating tape +PT100 | ||||||||
Receiving Bottle | Volume（L） | 2 | 5 | 5 | ||||||
Material | High borosilicate glass | |||||||||
Collection for Heavier Conponents | Heat Preservation | Heating tape +PT100 | ||||||||
Receiving Bottle | Volume（L） | 1 | 3 | 3 | ||||||
Material | High borosilicate glass | |||||||||
Vacuum System | First Stage Vacuum Pump | Type | Rotary Vane Vacuum Pump | |||||||
Pumping Rate(L/s) | 4 | 6 | 6 | |||||||
Ultimate vacuum（Pa） | 4*10-1（≤1Pa in the distillation system） | |||||||||
First Stage Vacuum Pump | Type | Difusion pump | ||||||||
Pumping Rate(L/s) | 80 | |||||||||
Ultimate vacuum（Pa） | 1*10-4（≤0.1Pa in the distillation system） | |||||||||
