Mini type Single Punch Tablet Press machine suitable for Small production with good quality in best price shanghai
This machine is designed for pressing round tablets from various granular materials, applicable to lab used for research and development and to small-scale production. as its feature, it is a small desk-top continuous press driven by motor or man-power. Only one set of punch and die is mounted, the depth of the filling material and the thickness of the tablets can be adjusted
Technical specifications:
|
Item |
TDP-1.5 |
TDP-5 |
TDP-6 |
|
Dies |
1 Set |
1 Set |
1 Set |
|
Max. Pressure |
15KN |
50KN |
60KN |
|
Max. Diameter. of Tablet |
12mm |
Round tablet 18mm, Irregular tablet 20mm |
Round tablet 20mm, Irregular tablet 25mm |
|
Max. Depth of Filling |
11mm |
18mm |
17mm |
|
Max.Thickness of Tablet |
6mm |
7mm |
7.5 mm |
|
Production Capacity |
5000 tablets/H |
4500 tablets/H |
3000 tablets/H |
|
Motor |
550W/220V |
750W/220V |
1.1-1.5kw/220V |
|
Machine Size |
570*450*625mm |
650*440*650mm |
750*380*695mm |
|
Net Weight |
90kg |
120kg |
165kg |
