Zp Rotary Tablet Press for Veterinary, Mothball, Animal Food, Salt
This machine is used to press various granular materials into tablets, such as the ring tablets or the elliptical tablets. The machine is suitable for small production capacity.The machine is fully closed, the surface of the inside rotary turret is made with stainless steel which can protect the surface, and prevent the cross contamination.The protective cover is made with PMMA through which it’s convenient for the operator to observe how the machine works. All the doors on the cover can be opened, and it’s easy to clean and maintain.
Technical parameters | ||||||||
Model | ZP17E | ZP19 | ||||||
Number of Station | 17 | 19 | ||||||
Max Main Pressure (KN) | 50 | 40 | ||||||
Max Pre-pressure (KN) | 10 | |||||||
Max Tablet Diameter (mm) | Round Tablet | 20 | 13 | |||||
Irregular Tablet | 22 | 16 | ||||||
Max Filling Depth(mm) | 15 | |||||||
Max Tablet Thickness (mm) | 6 | |||||||
Max Turret Speed (r/min) | 40 | |||||||
Max Production Capacity(pcs/h) | 40800 | 45600 | ||||||
Motor Power(KW) | 2.2 | |||||||
Overall size (mm) | 880*750*1600 | |||||||
Machine Weight (kg) | 500 | |||||||
Every factory machine is precisely debugged by engineers to ensure that it is ready for use after delivery
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical and chemical machinery and equipment in China. We belong to SINOPEC International Group.
In SINOPED you can get your desired goods with the best prices and good quality. Welcome your enquiries from all over the world.
