Mushroom Laminar Air Flow Filter FFU Fan Filter unit
- 1000 per Month
- T/T Credit Card
You May Like
-
Dust Free Rooms Fan Filter Unit (FFU) With H13 H14 U15 HEPA Filter
-
Fan Filter Unit FFU Clean Module EBM motor blower With Pre filter For 10-1000 Clean Room Laminar Flow HEPA Filter
-
Success way CE Certified ffu Cleanroom Fan Filter Unit
-
Cleanroom FFU hepa fan filter unit ffu for clean room
-
Laminar Flow Hood Hepa Fan Filter Unit FFU For Hospital
-
Fan Filter Unit FFU with hepa filter for cleanroom mushroom cultivation
Product Description
H14 HEPA filter unit FFU Fan filter Unit
H14 HEPA filter unit FFU Fan filter Unit can be used with modular linkage, and is widely used in the clean room with turbulent layer or laminar flow. It can be continuously run. And the air flow can reach to 0.45mm/s±20%. Long-life service, low noise, maintenance-free, small vibration, and adjustable speed. It can control thousands of units together. Before packing, it must pass the test according to the standard. The product is widely used in industries of semi-conductor, electronics, flat-panel screen, disc drive, optics and bio-engineering,etc. Customized design is available.
FFU Technical Parameters | ||||
Model | SINO-875/1 | SINO-920/1 | SINO-1175/1 | SINO-1225/1 |
Module Size(LxWxHmm) | 875x575x250 | 920x615x250 | 1175x575x250 | 1225x615x250 |
Plenum Chamber Material | Cold rolled steel with epoxy powder / Galvanized steel / Stainless steel | |||
Air Flow(m³/h) | 800 | 900 | 1000 | 1200 |
Average Velocity(m/s) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
Pressure(Pa) | 97(10mmAq) | 97(10mmAq) | 97(10mmAq) | 97(10mmAq) |
Power(W) | 100 | 100 | 100 | 100 |
Weight(Kg) | 25 | 27.5 | 34 | 37.5 |
Noise (db) | 52 | 52 | 52 | 52 |
HEPA Filter Size(LxWxH) | 870x570x69 | 915x610x69 | 1170x570x69 | 1220x610x69 |
HEPA Filter Efficiency | 99.997% 0.3µm | 99.997% 0.3µm | 99.997% 0.3µm | 99.997% 0.3µm |
HEPA Filter Frame | High-quality aluminum | High-quality aluminum | High-quality aluminum | High-quality aluminum |
HEPA Filter Pressure | 180pa 0.45m/s | 180pa 0.45m/s | 180pa 0.45m/s | 180pa 0.45m/s |
HEPA Filter Characteristics | Patented no-gap technology to make PU gasket | |||
Motor Parameter Power supply(V/Hz) | 220/50 | 220/50 | 220/50 | 220/50 |
Motor Parameter Type | Aluminum turbine motor | |||
Motor Parameter Vibration quotients(mm/s) | 0.2-0.5 | 0.2-0.5 | 0.2-0.5 | 0.2-0.5 |
There will no further notification if the appearance or parameters of our products are modified. Thanks.
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical and chemical machinery and equipment in China. We belong to SINOPEC International Group.
We have a well-experienced team to manufacture pharmaceutical machinery and equipments and a professional design institute. With rich experiences in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipments including clean room project, soft-gel production line, glass-lined reactor, fermentor, centrifuge, granulator, mixer, dryers, pulverizer, tablet press, soft and hard blister packing machine, capsule filling machines, cartoner and rollers, etc.
Due to our good credit and service, , we have made great achievements in the past years. We have established long-term business relations with many customers and some of our overseas customers have appointed us to be their purchase agency in China. Our products are exported to many countries & areas, Besides machinery and equipment, we also supply production lines and turn key projects.
In SINOPED you can get your desired goods with the best prices and good quality. Welcome your enquiries from all over the world.
One-year warranty period for whole machine except of tubes and human factors etc, and 12-month of after-sale service from the date when you receive machine or 12 months when installation finished;
Consultant services for whole machine life, and 24 hours technical support by email;
UPS, English software, user manual and the installation & debugging by our experienced technicians.
1. Can your machine meet our need well?
We will supply you a proposal as to your specific requirement, and each machine is customized to satisfy customer’s need well.
2. Are you a factory or a trading company?
We are the manufacturer, and have been in industry for more than ten years.
3. What's your payment way?
T/T by our bank account directly, or by Alibaba’s trade assurance service, or by the West Union, or in cash.
4. How can you ensure the machine’s quality after we put the order?
Before the delivery, we will send you machine’s pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.
5. We are afraid you won't deliver us the machine after we pay you the money.
Please note our above business license and certificates. And if you don't trust us, you can use Alibaba’s trade assurance service or by LC.
6. Why choose your company?
We have been engaged in the manufacturing of various packing machines professionally over 10 years, and we can provide better after-sales service.
