Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H

Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H thumbnail-1
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H thumbnail-2
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H thumbnail-3
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H thumbnail-4
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H photo-1
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H photo-2
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H photo-3
Pet/PP Plastic Packing Belt/Machinery Packing Belt Production Line/ Extrusion Machine/Making Machine 200kg/H photo-4
US$ 1000 - 98600 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Furuizhi
Place of Origin:
China
Model Number:
Customizable
Contact Supplier Request Quote Chat Now
Furuizhi (Suzhou) Intelligent Technology Co., LTD
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
china-shanghai-
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Furuizhi
Place of Origin China
Model Number Customizable
After-sales Service Provided Engineers available to service machinery overseas
Weight Customizable
Dimension(L*W*H) Customizable
Voltage Customizable
Application Plates
Condition New
Power(W) Customizable
Plastic Processed PE
Screw Design Single-screw

SJ90/30-PE  TPackage the belt production line configuration list

（1）、technical requirement

  1.Packing belt specification   9-19X1.0mm

Quantity:   Double root

  2.yield         5t/24h

  3.Power Supply         380V 50HZ  Three phase five line

  4.Factory requirements     L 50m×W 6m×H 6m

  5. water consumption        30m³Circulating water tank，0.2m³/min circulate；circle；round；loop

  6.gas consumption        pressure0.6MPa  0.1m³/min

(2)、Basic composition of the equipment

1、Spiral feeder                              2

2、1600LPre-dryer                             1

   3、CSG-3000  Molecular sieve dehumidifier     1

   4、Drying tower3000L                          1

   5、Adhesive agent gauge feeding               2

   6、SJ90-30single screw extruder               1

   7、Automatic screen changer                   1

   8、Metering pump                              2

   9、mould                                      2

   10、Water tank and dryer                      1

   11、First traction                            1

   12、constant temperature oven                 1

   13、First tensile preheater                   1

   14、The first stretch machine               1

   15、The second stretching machine comes with an embossing tractor                                        1

   16、oven and sink                           1

   17、Second traction                         1

   18、Double reel winder                      2

   19、moldTemperatureControiier               2


Product Tags: Pet PP Strap Band Production Line Strapping Belt Roll Extrusion Packing Strip Tape Making Machine , Pet Strap Production Line , PET packing belt machine , Pet belt production line , Pet packing belt extruder , Pet belt production line machine , Pet belt product
