Home > Products > mechanical equipment > High Speed Wire Cutting Machine
High Speed Wire Cutting Machine
- Tianjin
- T/T PayPal Cash Escrow
- 7 days
You May Like
-
Diameter Measuring Instrument Laser High-precision Twoway Laser Scanning External Diameter Measuring And Controlling Instrument Wire Enamelled Wire
-
Ellipticity Runout High-precision Automatic Diameter Measuring Instrument Height Outer Diameter Runout Measuring And Controlling Instrument Intelligent Online Measuring Instrument
-
High-frequency Spark Test Machine for Wire & Cable
-
Laser Diameter Gauge，Laser Micrometer
-
AutoWeigh Precision Powder/Tea/Granule Dispenser
-
Continuous Inkjet Printers，Case Coder， Wire And Cable, Laser Inkjet Printer
Product Details
| Brand Name | Yu Feng Industry | Place of Origin | China | |
| Model Number | YF-9781 | Usage | Twisting |
Product Description
High speed wire cutting machine is a kind of wire and cable equipment for continuous wire cutting in the process of operation. The equipment is suitable for high-speed and labor-saving line cutting working environment, saving time, labor and efficiency. Generally, it can be divided into thin line cutting machine and thick line cutting machine. Among them, the thin wire type high-speed wire cutting machine can be cut off Φ 4.0mm- Φ 10mm Round profile and 2.0mm-4.0mm thick × Flat line with width of 5.0mm-10mm. The thick line can be cut off Φ 4.0mm- Φ 16mm round profile and 2.0mm-4.0mm thick × Flat line with width of 11mm-24mm;
Main technical parameters:
type | YC-A | YC-B | YC-C |
Cutting speed | 180m/min 15Cpeces/min | 150m/min 120peces/min | 90m/min 100peces/min |
Cutting capacity | Round line: Q4 ~ ④ 10mm parallel line Tat: 2-4mm thick × 5-10mm wide | Round: ① P4~ φ 18mm parallel line fat: 2-8mm thick × 5-20mm wide | Round line: Medium 4 ~ 25mm parallel line Tat: 2-12mm thick × 5-30mm wide |
Cutting line length | 600mm-99999mm | 600mm~99999mm | 600mm~99999mm |
Line cutting accuracy | ±2%o | ±2%o | ±2%o |
Line taking mode | Wiring mode | Wiring mode | Wiring mode |
Tangent motor | 400w | 1500w | 3000w |
Main motor | 2.2kw | 4kw | 4kw |
Conveying motor | 1.5kw | 1.5kw | 2.2kw |
