Flexible Rubber Crane Cable, Type XQF 450/750V
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Jiangsu Shangshang Cable Group Co., Ltd
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Welding Cable /Rubber Flexible CableNegotiableMOQ: 1 Piece -
Variable Freqency Drive (VFD) Cable, EPR Insulated，0.6/1kVNegotiableMOQ: 1 Piece
-
Heavy-Duty Rubber Sheathed Flexible Cable For General Purpose 450/750VNegotiableMOQ: 1 Piece
-
UL 1032 PVC Insulated Appliance Wire 1000V (File No. E363159)NegotiableMOQ: 100 Pieces
-
Variable Freqency Drive (VFD) Cable, Silicone Rubber Insulated, 0.6/1kVNegotiableMOQ: 1 Piece
Brand Name
Jiangsu Shangshang Cable Group Co., Ltd
Place of Origin
China
APPLICATION:
This cable is suitable for low-speed moving port machinery, such as cranes, container cranes, etc. It can also be used for power supply of other types of mobile devices.
STANDARD:
Enterprise Standard Q/320481SS223
This cable is suitable for low-speed moving port machinery, such as cranes, container cranes, etc. It can also be used for power supply of other types of mobile devices.
STANDARD:
Enterprise Standard Q/320481SS223
CONSTRUCTION:
|
For cross-sectional area
1-5 cores, 3+1, 3+2, 6 – 20 cores
|
For cross-sectional area 95sqmm
3 phase cores + 3 earth cores (3C+3E)
|
|
-Conductor: flexible copper wires
-Insulation: EPR
-Filler(optional)
-Oversheath: CPE, black
|
-Conductor: flexible copper wires
-Insulation: EPR
-Filler
-Inner sheath: CPE, black
-Braided reinforced layer
-Oversheath: CPE, black
|
NUMBER OF CORES AND SIZE:
Single core: 0.75mm2 ～ 240mm22～4 cores：0.75mm2 ～ 70mm2
3+1 cores: 4mm2 ～ 70mm2
3+2 cores: 35mm2 ～ 70mm2
3+3 cores: 95mm2 ～ 240mm2
5 cores：1.5mm2 ～ 35mm2
6～20 cores：0.75mm2 ～ 4mm2
CORE IDENTIFICATION：
2 cores: brown, blue
3 cores：brown, black, gray
3+1 core：green-yellow, brown, black, gray
3+2 cores: green-yellow, brown, black, gray, blue
5 cores：green-yellow, brown, black, gray, blue
6 ～20 cores：black with white numbers
Note: other core identification colour is available upon request.
SHEATH COLOR：
black
USAGE CHARACTERISTIC:
Voltage: 450/750V
The continuous operating temperature: 70℃
The maximum cable temperature with short circuit (5S): 140℃
The minimum bending radius: 6D
