Automatic Vacuum Plastic Material Pellets Hopper Loader
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2010
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Power Plastic Auto Loader With Micro-Computer ControlNegotiableMOQ: 1 -
CE Certified Plastic Loading Machine Hopper Vacuum Loader for SaleNegotiableMOQ: 1
-
Low Cost Plastic Vacuum Autoloader for Injection Molding MachineNegotiableMOQ: 1
-
Hengju Hot Sale 300G Industrial Vacuum Auto Loader Hopper Loader for New Plastic MaterialNegotiableMOQ: 1
-
HAL-700G High Efficiency Automatic Plastic Granules Vacuum Hopper LoaderNegotiableMOQ: 1
Product Description
Separate Vacuum Hopper Loader:
1. Specially designed for material of large quantity.
2.High-power motor with large-sized hose and hopper.
3. Microcomputer controlled with alarm for overload and lack of material.
Notes:
The conveying capacity and loading distance is based on ABS raw materails accumulation density approx. 0.65kg/L, with 3-5mm diameter of palstic materials particles as testing samples, with vertical high 4m and horizontal distance 5m as testing standard to get results.
The exactly paremeter would not be the same as per different plastic proportion, figure, conveying length and heigh and pipeline feature etc.
Product Parameters
Model |
HAL-3HP |
HAL-5HP |
HAL-7.5HP |
HAL-10HP |
Motor(HP/KW) |
2.2KW |
3.75KW |
5.5KW |
7.5KW |
Conveying Capacity(Kg/h) |
590 |
820 |
1000 |
1300 |
Loading Distance(m) |
5 |
6 |
6 |
6 |
Static Wind Pressure(mm/h2o) |
2800 |
3200 |
4200 |
4500 |
Reservoir Volume(L) |
12 |
25 |
40 |
40 |
Hose Specification |
φ51mmx10m |
φ51mmx10m |
φ63mmx15m |
φ63mmx15m |
Dimension(cm) |
42x37x120 |
50x45x123 |
58x60x170 |
58x60x170 |
43x32x52 |
40x30x102 |
40x30x102 |
40x30x102 |
|
Approx.Net Weight(kg) |
68 |
90 |
135 |
140 |
6 |
10 |
12 |
12 |
