Injection Molding Machine SZ-2400A bottle cap making machine plastic injection machine
High quality and innovative products ,outstanding productivity ,efficient management ,perfect technical solutions and service.
shot weight:605g--845g
clamping force:240ton
screw diameter:55--65mm
space between tie bars:555x555mm
All our machines with CE/TUV approved!!!!
|
Technical Parameter |
||||
|
Item |
Unit |
Parameter |
||
|
INJECTION UNIT |
|
|
||
|
screw diameter |
mm |
55 |
60 |
65 |
|
screw L/D ratio |
L/D |
22.9 |
21 |
19.4 |
|
theoretical shot volume |
cm*3 |
665 |
791 |
929 |
|
shot weight(ps) |
g |
605 |
720 |
845 |
|
injection pressure |
Mpa |
210 |
176 |
150 |
|
theoretical injection rate |
g/s |
176.5 |
210 |
245 |
|
plastic capacity |
g/s |
26.4 |
32.5 |
40 |
|
CLAMPING UNIT |
|
|
||
|
max.clamping force |
KN |
2400 |
||
|
max.opening stroke |
mm |
530 |
||
|
space between tie bars |
mm |
555x555 |
||
|
mould height |
mm |
200-570 |
||
|
max.daylight |
mm |
1100 |
||
|
OTHER |
|
|
||
|
pump motor power |
KW |
22 |
||
|
pump pressure |
Mpa |
16 |
||
|
heating power |
KW |
18.5 |
||
|
size |
m |
6.2x1.6x2.1 |
||
|
net weight |
t |
8.0 |
||
|
oil tank capacity |
L |
440 |
||
Injection Molding Machine SZ-1600A
5-point twin toggle clamping system by modular optimization software designing. Strong clamping with rapid and stable, to meet the strict clamping condition.
|
Technical Parameter |
||||
|
Item |
Unit |
Parameter |
||
|
INJECTION UNIT |
|
|
||
|
screw diameter |
mm |
45 |
50 |
55 |
|
screw L/D ratio |
L/D |
23.3 |
21 |
19.1 |
|
theoretical shot volume |
cm*3 |
358 |
442 |
534 |
|
shot weight(ps) |
g |
326 |
402 |
486 |
|
injection pressure |
Mpa |
219 |
178 |
147 |
|
theoretical injection rate |
g/s |
142 |
175 |
212 |
|
plastic capacity |
g/s |
20.1 |
26.5 |
34.2 |
|
CLAMPING UNIT |
|
|
||
|
max.clamping force |
KN |
1600 |
||
|
max.opening stroke |
mm |
460 |
||
|
space between tie bars |
mm |
480x480 |
||
|
mould height |
mm |
180-500 |
||
|
max.daylight |
mm |
960 |
||
|
OTHER |
|
|
||
|
pump motor power |
KW |
18.5 |
||
|
pump pressure |
Mpa |
16 |
||
|
heating power |
KW |
13.6 |
||
|
size |
m |
5.3x1.35x1.9 |
||
|
net weight |
t |
5.6 |
||
|
oil tank capacity |
L |
420 |
||
|
international designation |
|
1600-785 |
||
