100GHz/200GHz DWDM Module in 1U Rackmount
US$ 1 - 500
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
flyin
Place of Origin:
China
Model Number:
DWDM
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
flyin
Place of Origin
China
Model Number
DWDM
Flyin Optronics’ 100GHz/200 GHz dense wavelength division multiplexer (DWDM module) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging to achieve optical add and drop at the ITU wavelengths. It provides ITU channel center wavelength, low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path . It can be used for wavelength add/drop in telecommunication network system.
Channel Spacing：
100GHz 200GHz
Channels：
4 Channel 8 Channel 16 Channel
Configuration：
Mux Demux
Fiber Type：
Bare fiber 900um loose tube 2mm cable 3mm cable
Fiber Length：
1m 2m
In/Out Connector：
None FC/APC FC/PC SC/APC SC/PC ST LC
1st Channel：
C21
C22
C23
C24
C25
C26
C27
C28
C29
C30
C31
C32
C33
C34
C35
C36
C37
C38
C39
C40
C41
C42
C43
C44
C45
C46
C47
C48
C49
C50
C51
C52
C53
C54
C55
C56
C57
C58
C59
C60
C61
| Features | Applications |
| Low Insertion Loss | Channel Add/Drop |
| Wide pass band | DWDM Network |
| High channel | Wavelength Routing |
| High stability and reliability | Fiber Optical Amplifier |
| Epoxy free on optical path | CATV Fiberoptic System |
Performance Specifications
| Parameter | 4 Channel | 8 Channel | 16 Channel | ||||
| Mux | Demux | Mux | Demux | Mux | Demux | ||
| Channel Wavelength（nm） | ITU Grid | ||||||
| Channel Spacing (GHz) | 100 / 200 | ||||||
| Channel Passband (@-0.5dB bandwidth (nm) | >0.3 | ||||||
| Insertion Loss (dB) | ≤1.8 | ≤3.0 | ≤4.5 | ||||
| Channel Uniformity (dB) | ≤0.6 | ≤1.0 | ≤1.5 | ||||
| Channel Ripple (dB) | 0.3 | ||||||
| Isolation（dB） | Adjacent | N/A | >30 | N/A | >30 | N/A | >30 |
| Non-adjacent | N/A | >40 | N/A | >40 | N/A | >40 | |
| Inertion Loss Temperature Sensitivity (dB/℃) | |||||||
| Wavelength Temperature Shifting (nm/℃) | |||||||
| Polarization Dependent Loss (dB) | |||||||
| Polarization Mode Dispersion（ps） | |||||||
| Directivity (dB) | ＞50 | ||||||
| Return Loss（dB） | ＞45 | ||||||
| Maximum Power Handling (mW) | 300 | ||||||
| Opterating Temperature (℃) | -5~+75 | ||||||
| Storage Temperature (℃) | -40~+85 | ||||||
| Package dimension (mm) | L432（482.6）xW250*H44 or Specify | ||||||
