Home > Manufacturing & Processing Machinery > Agricultural Machinery > Harvesting Machine > Multipurpose Vertical Axis Flow Rice Harvester Machine Highly Efficient Combine Harvester Price 12 Months Warranty
Multipurpose Vertical Axis Flow Rice Harvester Machine Highly Efficient Combine Harvester Price 12 Months Warranty
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2001
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap High Quality Paddy Cutting Machine Big Tank 1600L Combine Harvester Machine 42cc Hst Rice Harvester Price PhilippinesNegotiableMOQ: 1 -
High Efficiency Kubota Similar Rice Harvesting Machine With Good PriceNegotiableMOQ: 1
-
Kubota Similar DC70 Rice Combine Harvester for Agricultural PurposeNegotiableMOQ: 1
-
Original Manufacturer for 3 Row Corn Harvester and Maize Harvester and Maize Combine HarvesterNegotiableMOQ: 1
-
Agricultural Corn Maize Combine HarvesterNegotiableMOQ: 1
Multipurpose Vertical Axis Flow Rice Harvester Machine Highly Efficient Combine Harvester Price 12 Months Warranty
Main Parameter |
||||||||
No. |
Item |
Unit |
4LZ-5.5 Specification |
|||||
1 |
Model |
/ |
4LZ-5.5 |
|||||
2 |
Structure Type |
/ |
Vertical Axis Flow Full Feeding Rubber Crawler Self-propelled |
|||||
3 |
Engine |
Manufacture |
Zhejiang Xinchai Co.,Ltd |
|||||
Brand and Model |
/ |
YCD4J22T-1JT303 |
||||||
Type |
/ |
4-Cylinder,Vertical Engine,Water Cooled, DI-Injection, Turbocharged Engine |
||||||
Rated Power |
kW |
73(100HP) |
||||||
Rotating Speed |
r/min |
2400 |
||||||
4 |
Dimension（L*W*H）: |
Working State |
mm |
4850*3200*2500 |
||||
Transportation |
mm |
4850*2735*2300 |
||||||
5 |
Weight |
kg |
3550 |
|||||
6 |
Cutting Width |
mm |
2580 |
|||||
7 |
Feeding Capacity |
kg/s |
5.5 |
|||||
8 |
Minimum Ground Clearance |
mm |
310 |
|||||
9 |
Operation Speed |
km/h |
2.4 - 6.0 |
|||||
10 |
Productivity |
hm²/h |
0.3 - 0.8 |
|||||
11 |
Fuel Consumption |
kg/hm² |
18.5 - 40 |
|||||
12 |
Cutter Type |
/ |
Standard Type II |
|||||
13 |
Cutting Header Auger Type |
/ |
Telescopic Transverse Conveyor Auger |
|||||
14 |
Reel |
Type |
/ |
Eccentric Tooth(off center) |
||||
Diameter |
mm |
∮1000 |
||||||
Quantity |
pc |
5 |
||||||
15 |
Threshing Roller |
Quantity |
pc |
1 |
||||
Type |
/ |
Vertical Axis Flow Spike Tooth |
||||||
External(D*L) |
mm |
∮655*1877 |
||||||
16 |
Concave Sieve Type |
/ |
Grid |
|||||
17 |
Brake Type |
/ |
Wet Friction Plate |
|||||
18 |
Fan |
Type |
/ |
Centrifugal |
||||
Diameter |
mm |
∮346 |
||||||
Quantity |
pc |
1 |
||||||
19 |
Rubber Crawler |
Size |
/ |
500mm*90mm*53/56 |
||||
Track Gauge |
mm |
1190 |
||||||
20 |
Gear Box |
/ |
Hydraulic Stepless Speed Transmission(HST) |
|||||
21 |
Rethresher Type |
/ |
Auger Spike Tooth |
|||||
22 |
Grain Unloading Type |
/ |
Hydraulic Rate |
|||||
Rubber Track and Spare Parts For Harvester
DC60/70/Pro688 Kubota Combine Harvester
Q: What is your after-sale service？
A: 1. Online technical support. Our after-sales engineer will provide online guidance by internet or calling service at any time.
2. Technical training. We can freely arrange the engineers to work overseas to train your local after-sales team.
3. 12 months warranty period. we have one year guarantee for whole machine ( except quick-wear parts )、engine and gear box
4. We can supply operation and maintance manual in English
Q: Are there any optional parts for your combine harvesters ?
A: Yes, we can provide customized configurations such as grain tank type and rubber crawler width etc.
Q: How long is your delivery time ?
A: Normally it takes 15-20 days to deliver after your deposit receipt or L/C at sight.
Q: What is the payment term ?
A: 30% T/T in advance and balance before shipment, or Irrevocable L/C at sight
Q: Is OEM or ODM service acceptable ?
A: OEM service is no problem, if you have any special requirements about the machines, please kindly inform us, our engineering
department will study and offer you the suitable solution.
Q：How many sets of combine harvesters can be loaded in a 20’GP or 40’HQ.
A: A 20’GP can load 1 set and a 40’HQ can load 3 sets.
Q: Do I need to buy spare parts when purchasing the machines?
A: Yes, very neccessary. We hope that all customers can buy spare parts while purchasing the machines, spare parts are very
important for the combine harvester maintenance. Suggested spare parts list can be provided when you decide to purchase our
machines.
A: 1. Online technical support. Our after-sales engineer will provide online guidance by internet or calling service at any time.
2. Technical training. We can freely arrange the engineers to work overseas to train your local after-sales team.
3. 12 months warranty period. we have one year guarantee for whole machine ( except quick-wear parts )、engine and gear box
4. We can supply operation and maintance manual in English
Q: Are there any optional parts for your combine harvesters ?
A: Yes, we can provide customized configurations such as grain tank type and rubber crawler width etc.
Q: How long is your delivery time ?
A: Normally it takes 15-20 days to deliver after your deposit receipt or L/C at sight.
Q: What is the payment term ?
A: 30% T/T in advance and balance before shipment, or Irrevocable L/C at sight
Q: Is OEM or ODM service acceptable ?
A: OEM service is no problem, if you have any special requirements about the machines, please kindly inform us, our engineering
department will study and offer you the suitable solution.
Q：How many sets of combine harvesters can be loaded in a 20’GP or 40’HQ.
A: A 20’GP can load 1 set and a 40’HQ can load 3 sets.
Q: Do I need to buy spare parts when purchasing the machines?
A: Yes, very neccessary. We hope that all customers can buy spare parts while purchasing the machines, spare parts are very
important for the combine harvester maintenance. Suggested spare parts list can be provided when you decide to purchase our
machines.
