Help CenterTb Series 200A 125VDC DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector Manufacturers
Related Products
-
50A Tvb Series DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector ManufacturersUS$ 0.01 - 10MOQ: 100 Pieces -
100A Ts Series DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector ManufacturersUS$ 0.01 - 10MOQ: 100 Pieces
-
30A 600VDC Asl Series DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector ManufacturersUS$ 0.01 - 10MOQ: 100 Pieces
-
Tgxxxc Series 15A 450VDC DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector ManufacturersUS$ 0.01 - 10MOQ: 100 Pieces
-
Arl Series 30A 600VDC DC Alloy Atco Thermal Fuse Link Cutoff Motor Protector ManufacturersUS$ 0.01 - 10MOQ: 100 Pieces
Thermal-Link (DC-ATCO)-DC Alloy Type
Rated Current (Ir): 200 A
Rated Voltage (Ur): 100 VDC / 125 VAC
Rated Functioning Temp. (Tf): 102 ℃ ~ 136 ℃
UNIQUE
Xiamen SET Electronics Co., Ltd.
DC-Alloy Thermal-Link / DC-Alloy Thermal Cutoff (DC-ATCO) is defined as a non-resettable protective device functioning one time only. It is widely used in electrical equipment and electric vehicle. DC-ATCO is mainly consist of Thermal Element, Flux Resin, Case, Sealant and Lead Wires. Normally, thermal element is jointed to the two lead wires. Under abnormal conditions, when the temp. reaches to the fusing temp. of DC-ATCO, the thermal element melts and quickly retracts to the two lead wire ends with the aid of the flux resin and disconnects the circuit completely.
SETsafe | SETfuse DC-Alloy Thermal-Link is classified into Axial and Radial shapes, with Rated Current 10 A to 200 A, Rated Functioning Temp. 76 °C to 230 °C, with UL, cUL , Approvals and RoHS, REACH compliant.
● Non-Resettable
● High Accuracy of Functioning Temp.
● DC 200 A
● RoHS & REACH Compliant
Stud, Soldering
Radial
● EV Battery Modules
● Power Supplies
● Shape of Electrode Leads
For product quality, our goal is to be industry-leading. We ensure that the quality of the product meets the expected goals from the following process.
Quality Policy.
Qualified Supplier of Raw Materials.
IQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Process, Online Inspection and Testing (Function 100% Test).
IPQC (AQL, Dimension, Function, Visual Inspection).
FQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Reliability Test (AQL).
OQC (Packaging, Labeling, Quantity Inspection).
Agency (Safety Certificate) Annual, Quarterly Audits.
Quality Management System (TUV Approved and issued certificate).
SETsafe | SETfuse
