Petroleum Oil Air Release Properties Tester ASTM D3427 IP313 Lubricant air release value Analyzer DIN51585

Technical parameter

1. Applicable standards: ASTM D3427  IP313 DIN51585 NFT60151 SH/T0308

2. Electricity source: AC220±10% 50Hz±5%

3. Heating method: electric heating rod heating

4. Temperature control method: PID temperature controller

5. Temperature control range: normal temperature～80±1℃

6. Working pressure: 19.6Kpa

7. Pressure control: precise pressure regulating valve adjustment

8. Timing method: digital display timer

9. Pressure display: digital meter display

10. Machine power: 1500W

11. Instrument size: 340*400*560mm

12. Net weight: 25KG

Main feature

1. High-quality Omron PID thermostat, digital display temperature, accuracy 0.1℃

2. Digital display air pressure, with needle valve adjustment;

3. Automatically control the blowing time, and automatically record the defoaming time after blowing, with an accuracy of 0.01s;

4. The press-type liquid circulation joint can quickly and conveniently disassemble the test tube;

5. Safety protection device to prevent the liquid level from being too low;

6. Two sets of constant temperature tests can be carried out at the same time;

7. The sputtering multi-channel liquid circulator can well ensure the temperature uniformity of each point
