Lubricating Oil liquidity Tester DIN51568 Lubricant Fluidity Analyzer Petroleum Oil Mobility Apparatus Flow of Lubricating Oils

Technical Parameter

1. Applicable standard: DIN51568  GB/T12578

2. Refrigeration method: dual compressor refrigeration

3. Temperature range: normal temperature～-80℃

4. Temperature control method: digital display PID temperature controller

5. Power of the whole machine: 1KW

6. Working unit: 2 tubes

7. Pressure range: 980±10PA

8. Working power supply: AC220,240V/50.60HZ

Performance characteristics

1. Double compressor cascade refrigeration to ensure the supply of cooling capacity;

2. Microcomputer temperature controller, digital display, accuracy ±0.2℃ PT100 sensor;

3. The glass Dewar bottle is used as a cold bath, and the heat preservation effect is good;

4. The split structure can reduce the damage caused by the vibration of the instrument;

5. Stainless steel heater;

6. The evaporator adopts copper chrome-plated coil;

7. There is sunlight behind the Dewar flask, which is convenient for observation;

8. The unique stainless steel clamping system can quickly clamp the test tube;

9. The special glass test tube meets the standard requirements;

10. Digital display of pressure, adjustment of precision gauge type.
