Help CenterSHOT PEENING MACHINE
Related Products
Shot peening machine is a process specifically designed to enhance the fatigue strength of components which are subject to high alternating stress. It can help to prevent fatigue cracks, corrosion, deteriorated strength and premature fatigue that can be caused by machining and form metal parts which also creates internal stress concentration. It also helps to prevent crack formation and growth since typically fatigue cracks generally begin at the imperfection on the surface of the material.
Application of shot peening machine:
Crankshafts
Gear wheels
Connecting rods
Automotive gear parts
Coil springs
Turbine blade (Aircraft)
Airframe components
Suspension springs
Medical implants
Technical specification of shot peening machine
Items |
unit |
QGHP400 |
QGHP500-1 |
QGHP500-2 |
QGHP500-3 |
Max working size |
mm |
Φ400*600 |
Φ500*1100 |
Φ500*1100 |
Φ500*1100 |
Max loading weight |
kg |
200 |
500 |
500 |
500 |
Blast wheel quantity |
1 |
2 |
2 |
2 |
|
Number of chamber |
2 |
2 |
3 |
4 |
Advantages Of Shot Peening:
It reduces stress corrosion splitting
It can prepare components for plating
It straightens fragments that were deformed when manufactured
It reduces casting permeability
It can alter part dimensions
It will improve oil retention
Transportation System:
2-4 rotating carousel chambers allow one chamber to process (shot blasting or peening) while others to load and unload work-pieces. A higher production efficiency is insured.
Hanger with self rotating function keep work-pieces rotating while processing for a high abrasive coverage.
Blasting chamber:
The engineering team uses 3-D dynamic simulation design blast turbines layout to ensure that the steel shot ray can cover the surface of the workpiece 360 degrees.
Shot blasting chamber with Mn13 steel guard plate which has high impact toughness and high service life, fully realize the reflection funcation of abrasive and improve the cleaning quality. That we promise 10 years maintenance-free warranty to blasting chamber.
QINGGONG MACHINERY is a professional shot blasting machine manufacturer, we provide shot blasting machine, shot peening machinery, servo punch press, roller punching machine, shot blasting machine china and etc. Want to know blasting media comparison or more? Please contact us.
