Tumble belt shot blasting machine or crawler shot blasting machine is the most universal among all shot blasters as their design makes them suitable for processing parts of different sizes in bulk loads. Shot blasting of casts, forged and pressed parts, remodelled cold or hot, of various complicated forms, springs, etc. (weighing up to 20 kg and manufactured in smaller and large series, the volume of a particular filling may be up to 500 L, mass up to 1,000 kg), cleaning surface, removing casting sand and filings and consolidating the surface (microhandling), roughing the surface before colouring, etc. Our company has tumble blaster for sale.
Machines have a perpetual caterpillar made from perforated rubber belt. Treated objects are put by a special filling contraction to the caterpillar. When caterpillar moves its special shape causes treated objects to turn and roll, which causes the whole surface of the treated object to be quality blasted in a jet of abrasive. For emptying, the caterpillar is started-up in the opposite direction turning mode.
The machine's housing is protected by wear-resistant manganese steel. High efficiency of the machine is provided by the system for continued returning and cleaning of the abrasive, along with efficient turbines made from wear-resistant materials.
Standard equipment of larger machines includes PLC Siemens, display, timer automatic or manual mode, automatic start-up of turbines, working-hours counter, etc.
The machine may be equipped with a magnetic separator, vibration conveyor and variable frequency drive for the turbines.
Machines have a perpetual caterpillar made from steel flaps. Treated objects are put by a special filling contraction to the caterpillar. When caterpillar moves its special shape causes treated objects to turn and roll, which causes the whole surface of the treated objects to be quality blasted in a jet of abrasive. For emptying, the caterpillar is started-up in the opposite direction turning mode. Tumble belt shot blasting machine with manganese steel belt, the volume of a particular filling may be up to 2,000 L, mass up to 5,000kg.
