EN ISO 4589-2:Oxygen Index Test to Plastics Material

EN ISO 4589-2: Plastics – Determination of burning behaviour by oxygen index – Part 2: Ambient- temperature test.

EN ISO 4589-2:Oxygen Index Test to Plastics Material - Scope

This part of ISO 4589 specifies methods for determining the minimum concentration of oxygen,

in admixture with nitrogen, that will support combustion of small vertical test specimens under

specified test conditions. The results are defined as oxygen index values.

Methods are provided for testing materials that are self-supporting in the form of vertical bars or sheet up to 10,5 mm thick. These methods are suitable for solid, laminated or celluar materials characterized by an apparent density greater than 100 kg/m3.

The methods may also be applicable to some cellular materials having an apparent density of less than 100 kg/m3. A method is provided for testing flexible sheet or film materials while supported vertically. For comparative purposes, a procedure is provided for determining whether or not the oxygen index of a material lies above some specified minimum value.

Oxygen index results obtained using the methods described in this part of ISO 4589 can provide a sensitive measure of the burning characteristics of materials under certain controlled laboratory conditions, and hence may be useful for quality control purposes. The results obtained are dependent upon the shape, orientation and isolation of the test specimen and the conditions of ignition. For particular materials or applications, it may be necessary or appropriate to specify different test conditions. Results obtained from test specimens of differing thickness or by using different ignition procedures may not be comparable and no correlation with flammability behaviour under other fire conditions is implied.

Results obtained in accordance with this part of ISO 4589-2 must not be used to describe or appraise the fire hazard presented by a particular material or shape under actual fire conditions, unless used as one element of a fire risk assessment that takes into account all of the factors pertinent to the assessment of the fire hazard of a particular application for the material.

EN ISO 4589-2:Oxygen Index Test to Plastics Material - Principle

A small test specimen is supported vertically in a mixture of oxygen and nitrogen flowing upwards through a transparent chimney. The upper end of the specimen is ignited and the subsequent burning behaviour of the specimen is observed to compare the period for which burning continues, or the length of specimen burnt, with specified limits for such burning. By testing a series of specimens in different oxygen concentrations, the minimum oxygen concentration is estimated. Alternatively, for comparison with a specified minimum oxygen index value, three test specimens are tested using the relevant oxygen concentration, at least two of which are required to extinguish before any relevant burning criterion is exceeded.

EN ISO 4589-2:Oxygen Index Test to Plastics Material - relative standards

IEC 60695-11-10 Fire hazard testing - Part 11-10: Test flames -50 W horizontal and vertical flame test methods

UL 94 Test For Flammability of Plastic Materials for Parts in Devices and Appliances

UL1581:2009 Reference standard fo electrical wires cables,and flexible cords VW-1(clause 1080)

IEC 60695-2-11-2000 (GB 5169.11) Fire hazard testing — Part 2-11: Glowing/hot-wire based test methods — Glow-wire flammability test method for end-products

IEC 60695-2-12-2000 (GB 5169.12) Fire hazard testing — Part 2-12: Glowing/hot-wire based test methods — Glow-wire flammability test method for materials

IEC 60695-2-13-2000 (GB 5169.13) Fire hazard testing — Part 2-13: Glowing/hot-wire based test methods — Glow-wire ignitability test method for meterials

ASTM D 2863Standard Test Method for Measuring the Minimum Oxygen Concentration to Support Candle-Like Combustion of Plastics (Oxygen Index)
