Parker PV140 PV180 PV270 Hydraulic Piston Pump,PV140 Hydraulic Pump
Parker PV140 Hydraulic Piston Pump PV140 Oil Pump
Parker PV016, PV020, PV023,PV032, PV040, PV046, PV063, PV080, PV092, PV140, PV180, PV270 hydraulic PV series axial piston pump
Features:
lInstallation form conforms to standard VDMA-24560
lStandard mounting: IS0 3019/2 4-hole flange (metric)
l Optional installation: IS0 3019/1 4-hole flange (SAE)
l Large variable control piston with strong reset spring, quick response
l Because the compensation system has the function of pressure release, the pressure peak value of zero flow variable is reduced
l At low T pressure, it still has stable compensation regulation function: the minimum compensation pressure is 12-15bar
l 9. Plunger design and new technology of pre-compression volume reduce flow pulsation to unprecedented minimum level
l Robust and FEM optimized pump body structure reduces noise level intact variable control types
l 100% nominal torque through shaft transmission structure
l The same specification, the same type and almost all pumps with the same metric or SAE mounting flange can be assembled
This type of hydraulic pump is a swashplate type axial plunger type hydraulic pump driven by belt pass shaft for open loop, which can be used in combination of single pump and multiple pumps.
Parker PV series Technical Features:
- Low noise level
- Fast response
- Service-friendly
- High self-priming speed
- Compact design
- Thru drive for 100% nominal torque
Control mode:
With standard pressure regulator
With power regulator
Working pressure:
Rated pressure 35MPa
Peak pressure 42MPa
