Product Details
Brand Name: | SAIMO | Place of Origin: | China | Model Number: | FH-01-6000P |
Use: | Computer |
Product Description
SAIMO FH-01-6000P Feeder Controller With Good Price In Stock
Saimo belt scale in feeder is specially designed for weighing material which is continuously passing through the conveyor. Automatic operation is achieved without intervention of the operator. The electronic belt scale is typically comprised of three parts: load cell, weigh frame and secondary electronics. The 6105 controller serves as one of the Saimo customized secondary electronics. This manual provides the information necessary for installation, operation, maintenance and service of the 6105 controller. The 6105 controller is available in panel mount and field mount. By processing the weight signal from the load cell and the speed signals from the speed sensor, It calculates and displays flow rate and total of the material fed.
Features
Saimo 6105 controller is specially designed for belt scales, meeting all measuring and control requirements on typical applications. The software has been solidified into the memory chip. Each preprogrammed function can be activated automatically by operating from the keypad or installing the optional expansion board. Saimo 6105 controller has a powerful and user friendly operating interface, easy for function selection, data setup, operation and maintenance. The following functions have been completed into Saimo 6105 controller.
Saimo feeder controller has two types of FH-05 and FH-02 (old model 6105 and 6105B) type. FH-05 (6105) is based on 32-bit microprocessor control, the display uses 320X240 dot matrix LCD large screen display. FH-02 (6105B) is based on CPU with 8-bit microprocessor, 128X64 dot matrix display with liquid crystal display.
Main features and features:
● Digital Instrumentation: provide accurate, drift-free performance;
● automatic zero adjustment: through a simple operation, the instrument will automatically calculate and establish a new zero:
● Automatic calibration: to provide users hang code calibration chain code calibration, electronic calibration and a variety of physical calibration automatic calibration mode;
● zero tracking: the system can automatically zero tracking;
● programmable features: programmable Instrumentation input and output ports to meet the requirements of different users;
● filter choices: filter time is adjustable;
● zero dead zone: eliminate the dead zone by setting zero interference small flow;
● speed input options: choose both internal and external speed input;
● enter password: protection parameters to prevent human modification;
● fault self-diagnosis: can Multi-channel load cell failure to self-diagnosis
Instrument parameters:
● Enclosure
Panel Mount: Dimensions: 299 x 154 x 203mm
Opening size: 142 X 287mm
● Temperature
Operating temperature: -10 ~ 50 ℃
Storage Temperature: -40-701C
● power supply: 220VAC, 50Hz
● digital signal input / output:
Three-way programmable digital input the instrument accepts input from a variety of switching equipment;
four programmable digital output (relay, passive contact) signal is used to provide a variety of information or trigger a variety of auxiliary equipment;
● speed input: single speed pulse input from the speed sensor:
● analog input / output:
Input: load cell millivolt signal;
Output: one for standard 0-20mA or 4-20mA current output flow;
● control: way PID regulator control output;
● communication: optional RS232 or RS485 communication interface, PROFIBUS fieldbus interface (for increased input / output interfaces and other communication, please contact with the factory.).
